Foxboro IDP10S-TF1B03AA-L1 Advanced Differential Pressure Transmitter
Foxboro
Product Code: IDP10S-TF1B03AA-L1
Brand: Foxboro
GET OFFER: info@imtek.com.tr
Description for Foxboro IDP10S-TF1B03AA-L1 Advanced Differential Pressure Transmitter
Base Model: IDP10S-TF1B03AA-L1 PSS Reference: 2A-1S10A FUNCTION: Measures the Difference Between Two Pressures and Transmits a Proportional or Square Root (Flow) Electrical Signal. Accuracy Expressed as Percentage of Reading. ELECTRONICS VERSION AND OUTPUT SIGNAL: HART & 4 To 20 mA STRUCTURE CODE: Prepared For Schneider Direct Connect Seal On High Side (Flanged PSFLT Or Sanitary PSSCT Or PSSST) & 1/2 NPT Connection on Low Side; Silicone Fill In Sensor SPAN LIMITS: 0.5 and 200 inH2O; 0.12 and 50 kPa; 1.2 and 500 mbar PROCESS CONNECTOR: (Matl Same As Process Cover) 1/2 NPT 316 ss, Process Connector On Low Side CONDUIT CONNECTION & HOUSING MATERIAL: 1/2 NPT Conduit Connection, Both Sides, 316 ss Housing ELECTRICAL SAFETY: ATEX Intrinsically Safe, Ex ia IIC OPTIONAL MODEL SUFFIX(ES) INCLUDED: Digital Indicator, Internal Pushbuttons, nd Window Cover 2 Instrument Tag blank Output Range 0 - 0,497 barRecommended Products For Foxboro
