The KL9070 shield terminal provides eight terminal points with the potential of the mounting rail and enables the screening to be picked up without further modular terminal blocks or wiring. With its internal seamless copper surface, the KL9070 offers good screening between two Bus Terminals.
Technical dataKL9070Nominal voltage≤ 60 VCurrent load≤ 10 AIntegrated fine-wire fuse–Diagnostics–Power LED–Defect LED–Reported to K-bus–PE contact–Shield connection8 xRenewed infeed–Connection facility to additional power contactnoK-bus, looped throughyesBit width in the process image0Electrical connection to DIN railyesCurrent consumption K-bus–Electrical isolationyesHousing width12 mmSpecial featuresdissipation of EMC interference via large copper surfaces on the DIN railWeightapprox. 50 gSide by side mounting on Bus Terminals with power contactyes, left without PESide by side mounting on Bus Terminals without power contactyesOperating/storage temperature0…+55 °C/-25…+85 °CApprovals/markingsCE, UL, ATEXEx markingII 3 G Ex nA IIC T4 Gc
