KL3202 | 2-channel input terminal PT100 (RTD)
The KL3202 analog input terminal allows resistance sensors to be connected directly. The Bus Terminal’s circuitry can operate the sensors using 2-wire or 3-wire connection techniques. Linearisation over the full temperature range is realised with the aid of a microprocessor. The temperature range can be selected freely. The Bus Terminal's standard setting is: resolution 0.1 °C in the temperature range of PT100 sensors in 3-wire connection. The run LEDs give an indication of the data exchange with the Bus Coupler. The error LEDs indicate sensor faults (e.g. a broken wire).
Technical dataKL3202 | KS3202Number of inputs2Power supplyvia the K-busTechnology2-/3-wireSensor typesPT100, PT200, PT500, PT1000, Ni100, Ni120, Ni1000 resistance measurement (e.g. potentiometer, 10 Ω…1.2/5 kΩ)Connection method2- or 3-wire (default: 3-wire)Measuring range-200…+850 °C (PT sensors); -60…+250 °C (Ni sensors)Resolution0.1 °C per digitConversion time~ 250 msMeasuring currenttyp. 0.5 mAMeasuring error< ±1 °CElectrical isolation500 V (K-bus/signal voltage)Current consumption power contacts– (no power contacts)Current consumption K-bustyp. 60 mABit width in the process imageinput: 2 x 16 bit data (2 x 8 bit control/status optional)Configurationno address setting, configuration via Bus Coupler or controllerSpecial featuresopen-circuit recognitionWeightapprox. 70 gOperating/storage temperature-25…+60 °C/-40…+85 °CRelative humidity95 %, no condensationVibration/shock resistanceconforms to EN 60068-2-6/EN 60068-2-27EMC immunity/emissionconforms to EN 61000-6-2/EN 61000-6-4Protect. class/installation pos.IP 20/variablePluggable wiringfor all KSxxxx Bus TerminalsApprovalsCE, UL, Ex, GLSpecial terminalsKL3202-0010PT200KL3202-0011PT200 in Siemens S5 formatKL3202-0012PT500KL3202-0013PT500 in Siemens S5 formatKL3202-0014PT1000KL3202-0015PT1000 in Siemens S5 formatKL3202-0016Ni100KL3202-0017Ni100 in Siemens S5 formatKL3202-0020resistance measurement 0…1.2 kΩKL3202-0021PT100 in Siemens S5 formatKL3202-0023Ni120KL3202-0024Ni120 in Siemens S5 formatKL3202-0025Ni1000KL3202-0026Ni1000 in Siemens S5 formatKL3202-0027resistance measurement 10…10 kΩKL3202-0028Resolution increased to 0.01 °C; the measurement range is reduced to -40 °C to +128 °C. The absolute accuracy is 0.3 °C, differential error is 0.1 °C.KL3202-0029Ni1000 per Landis&Staefa characteristic curve (Siemens, 100° corresponds to 1500 Ω)
