HEIDENHAIN LB 382 Single SectionSealed Linear Encoder Image

HEIDENHAIN LB 382 Single SectionSealed Linear Encoder

HEIDENHAIN

Product Code: LB 382 Single Section
Brand: HEIDENHAIN



GET OFFER: info@imtek.com.tr

Description for HEIDENHAIN LB 382 Single SectionSealed Linear Encoder

Specifications LB 382 up to ML 3 040 mm Measuring standard Coefficient of linear expansion Rustproof steel scale tape with AURODUR graduation, grating period 40 µm ?therm  10 x 10–6 K–1 Accuracy grade ±5 µm Measuring length ML* in mm Single-section housing 440 640 840 1040 1240 1440 1640 1840 2040 2240 2440 2640 2840 3040 Reference mark* LB 382 LB 382 C Selectable by selector plate every 50 mm, standard setting: 1 reference mark in the center Distance-coded Interface ? 1 VPP Signal period 40 µm Diagnostics interface Analog Cutoff frequency –3 dB ? 250 kHz Electrical connection Separate adapter cable (1 m/3 m/6 m/9 m) connectible to mounting block Cable length1) ? 150 m Voltage supply without load DC 5 V ±0.25 V/< 150 mA Traversing speed ? 120 m/min (max. acceleration in measuring direction ? 60 m/s2) Required moving force ? 15 N Vibration 55 Hz to 2000 Hz Shock 11 ms ? 300 m/s2 (EN 60 068-2-6) ? 300 m/s2 (EN 60 068-2-27) Operating temperature 0 °C to 50 °C Protection EN 60 529 IP53 when mounted according to the instructions and mounting information IP64 if compressed air is connected via DA 400 Mass 1.3 kg + 3.6 kg/m measuring length * Please select when ordering 1) With HEIDENHAIN cable
