HEIDENHAIN LC 415 Sealed Linear Encoder

HEIDENHAIN

Product Code: LC 415
Brand: HEIDENHAIN



GET OFFER: info@imtek.com.tr

Description for HEIDENHAIN LC 415 Sealed Linear Encoder

SpecificationsLC 415LC 415LC 485Measuring standardCoefficient of linear expansionDIADUR glass scale with absolute track and incremental track, grating period 20 µm?therm  8 x 10–6 K–1 (mounting type I/II); with mounting spar: ?therm  9 x 10–6 K–1 (mounting type III)Accuracy grade*±3 µm, ±5 µmMeasuring length ML* in mmMounting spar* or clamping elements* up to ML 1240 optional, necessary as of ML 1340 70 120 170 220 270 320 370 420 470 520 570 620 670 720770 820 920 1020 1140 1240 1340 1440 1540 1640 1740 1840 2040Functional safetyfor applications up to• SIL-2 according to EN 61 508• Category 3, PL 'd” according to EN ISO 13 849-1:2008–PFH? 15 x 10–9 (up to 6000 m above sea level)–Safe position1)Encoder: ±550 ?m (safety-related meas. step SM = 220 ?m)–Mechanical connection: fault exclusions for loosening of the housing and scanning unit (page 21)InterfaceEnDat 2.2Ordering designationEnDat22EnDat02Measuring step At ±3 µmAt ±5 µm0.001 µm0.010 µm0.005 µm0.010 µmClock frequency (calculation time tcal)? 16 MHz (? 5 µs)? 2 MHz (? 5 µs)Incremental signals–? 1 VPP (20 µm)Cutoff frequency –3 dB–? 150 kHzElectrical connectionSeparate adapter cable (1 m/3 m/6 m/9 m) connectible to mounting blockCable length? 100 m2)? 150 m2)Voltage supplyDC 3.6 V to 14 VPower consumption (max.)3.6 V: ? 1.1 W; 14 V: ? 1.3 WTraversing speed? 180 m/min (max. acceleration in measuring direction ? 100 m/s2)Required moving force? 5 NVibration 55 Hz to 2000 Hzeffecting theShock 11 msScanning unit: ? 200 m/s2 (EN 60 068-2-6)Housing without mounting spar: ? 100 m/s2 (EN 60 068-2-6)Housing with mounting spar, and cable outlet at right: ? 150 m/s2, left: ? 100 m/s2 (EN 60 068-2-6)? 300 m/s2 (EN 60 068-2-27)Operating temperature0 °C to 50 °CProtection EN 60 5293)IP53 when installed according to instructions in the brochure, IP64 with sealing air from DA 400MassEncoder: 0.2 kg + 0.55 kg/m measuring length; mounting spar: 0.9 kg/m* Please select when ordering1) Further tolerances may occur in subsequent electronics after position value comparison (contact manufacturer of subsequent electronics)2) With HEIDENHAIN cable; cock frequency ? 8 MHz3) In the application the LC must be protected from the intrusion of particles and liquids
