HEIDENHAIN LS 328 C Sealed Linear Encoder

HEIDENHAIN

Product Code: LS 328 C
Brand: HEIDENHAIN



GET OFFER: info@imtek.com.tr

Description for HEIDENHAIN LS 328 C Sealed Linear Encoder

Incremental Specifications LS 388 C LS 328 C Measuring standard Glass scale with DIADUR graduation Accuracy grade ± 10 µm Measuring length ML* 70, 120, 170, 220, 270, 320, 370, 420, 470, 520, 570, 620, 670, 720, 770, 820, 870, 920, 970, 1020, 1140, 1240 Incremental signals 1 VPP TTL Grating period 20 µm Edge separation a – ? 5 µs Reference mark Distance-coded Recommended measuring step1) 10 µm, 5 µm Power supply 5 V DC ± 5 %/< 100 mA (without load) Electrical connection Separate adapter cable connectable to mounting block Cable length ? 30 m (with HEIDENHAIN cable) Traversing speed ? 60 m/min Required moving force ? 5 N Vibration 55 Hz to 2 000 Hz Shock 6 ms ? 150 m/s2 (EN 60 068-2-6) ? 300 m/s2 (EN 60 068-2-27) Operating temperature 0 °C to 50 °C Protection EN 60 529 IP 53 when mounted according to the instructions Weight 0.27 kg + 0.67 kg/m ML * Please select when ordering 1) For position measurement
