HEIDENHAIN ROC 2310 1110410-01 Angle Encoder With Integral Bearing
HEIDENHAIN
Product Code: ROC 2310
Artikelnummer: 1110410-01
Brand: HEIDENHAIN
GET OFFER: info@imtek.com.tr
Description for HEIDENHAIN ROC 2310 1110410-01 Angle Encoder With Integral Bearing
Measuring standard DIADUR graduation on glass disk Measuring method absolute (singleturn) System accuracy ± 5" Maximum position error per signal period ± 0.4" Mechanical device version Solid shaft for separate shaft coupling Shaft type Solid shaft Shaft diameter 10 mm Flange version Rectangular flange with 80 mm centering collar, aluminum Interface EnDat 2.2 Ordering designation EnDat22 Positions per revolution 67108864 (26 bit) Electrical permissible speed ? 3000 min?¹ Clock frequency ? 16 MHz Calculation time tcal 5 µs Incremental signals without Output signals per revolution 16384 Cutoff frequency (-3 dB) no specified value Permissible cable length (with HEIDENHAIN cable) ? 150 m Power supply DC 3.6 V ... 14 V Typical current consumption without load ? 140 mA at 5 V Power consumption ? 1.1 W at 3.6 V ? 1.3 W at 14 V Connecting direction Cable outlet for axial and radial use Cable type PUR Ø 6.0 mm Cable length 1 m Electrical connection Coupling M12, male, 8-pin Mechanical permissible speed ? 3000 min?¹ Starting torque at 20 °C 0.02 Nm Moment of inertia of the rotor (shaft) 0.000050 kgm² Shaft load axial 30 N radial 30 N at shaft end Vibration 55 Hz to 2000 Hz (EN 60068-2-6) ? 200 m/s² Shock 6 ms (EN 60068-2-27) ? 1000 m/s² Maximum operating temperature ? +60 °C Minimum operating temperature ? -20 °C Degree of protection IP 64 (EN 60529) Mass 1.0 kgRecommended Products For HEIDENHAIN
