HEIDENHAIN RON 786C 355884-03 Angle Encoder With Integral Bearing
HEIDENHAIN
Product Code: RON 786C
Artikelnummer: 355884-03
Brand: HEIDENHAIN
GET OFFER: info@imtek.com.tr
Description for HEIDENHAIN RON 786C 355884-03 Angle Encoder With Integral Bearing
Measuring standard DIADUR graduation on glass disk Measuring method incremental System accuracy ± 2" Maximum position error per signal period ± 0.7" Mechanical device version Hollow shaft with integrated stator coupling Shaft type Hollow through shaft Shaft diameter 60 mm Flange version Flange with 200 mm outside diameter and 180 mm centering collar, drainage channels, aluminum Interface 1 Vpp Cutoff frequency (-3 dB) ? 180 kHz Reference mark distance-coded Nominal increment of reference marks 1000C Line count 18000 Incremental signals 1 Vpp Power supply DC 5 V (±10 %) Total current without load ? 150 mA Connecting direction Cable outlet for axial and radial use Cable type PUR Ø 6.0 mm Cable length 1 m Electrical connection free cable end Permissible cable length (with HEIDENHAIN cable) ? 150 m Mechanical permissible speed ? 1000 min?¹ Starting torque at 20 °C ? 0.5 Nm Moment of inertia of the rotor (shaft) 0.0012 kgm² Permissible axial motion of measured shaft ± 0.1 mm Natural frequency ? 1000 Hz Vibration 55 Hz to 2000 Hz (EN 60068-2-6) ? 100 m/s² Shock 6 ms (EN 60068-2-27) ? 1000 m/s² Maximum operating temperature ? +50 °C Minimum operating temperature ? 0 °C Degree of protection IP 64 (EN 60529) Mass 2.5 kgRecommended Products For HEIDENHAIN
