Hengesbach TPF100 Front-mounted pressure and level transmitter

Hengesbach

Product Code: Hengesbach TPF100 Front-mounted pressure and level transmitter
Artikelnummer: TPF100
Brand: Hengesbach



GET OFFER: info@imtek.com.tr

Description for Hengesbach TPF100 Front-mounted pressure and level transmitter

Featuresprecise measurements with ? ± 0,15% FSwide range of process connections for hygienic applicationsTurnDown 10vacuum-proof piezoresistive measuring cell with stainless steel membranemeasuring ranges from 100mbareasy to clean an high protection classes IP 67 und IP69Kintegrated on-site display or external OPUSM display and operating module for parametrisation and display of measuring valuesapplication strengths: measurement of content of pressured tanks / vacuum measurements with high temperaturesDescriptionThe TPF pressure transmitters are suitable for taking pressure and filling level measurements in pipelines and containers. The wide range of hygienic process connections enables use in all applications in the food and pharmaceutical industries. Customer-specific process connections are also possible on request.display and operating module OPUSMThe vacuum-proof measuring cell with stainless steel membrane works on the basis of the piezoresistive measuring principle The TPF pressure transmitters are designed to measure from -1/0…0.35 to -1/0…100 bar. Special measuring ranges are also available on request. Given the nature of the design for long-term medium temperatures of up to 125°C / 200°C, CIP and SIP cleaning methods can be used on the transmitters. The high protection classes of IP67 and IP69K also mean that the devices can be safely cleaned on the outside with foam and a high-pressure cleaner and that moisture is reliably prevented from entering into the device. For additional protection against moisture, the electronics are fully encapsulated in the housing.All the pressure transmitters in series 100/101 are designed for universal applications and, in particular, for applications with constantly high temperatures of up to 200°C. Furthermore, using the on-site display with series 100 and the display and operating module OPUSM in series 101, the pressure transmitters can be simply read out, configured and diagnosed.
