Hirschmann 5Tx 943824-002 Railswitch Spider
Hirschmann
Product Code: 5Tx 943824-002 Railswitch Spider
Brand: Hirschmann
GET OFFER: info@imtek.com.tr
Description for Hirschmann 5Tx 943824-002 Railswitch Spider
More InterfacesPower supply/signaling contact1 plug-in terminal block, 3-pin, no signal contactNetwork size - Length of cableTwisted pair (TP)0 - 100 mNetwork size - CascadibilityLine - / star topologyanyPower requirementsOperating voltage9.6 VDC - 32 VDCCurrent consumption at 24 V DCmax. 100 mAPower consumptionmax. 2.2 W; 7.5 Btu(IT)/h at 24 VDCServiceDiagnosticsLEDs (power, link status, data, data rate)Ambient conditionsOperating temperature0 C to +60 CStorage/transport temperature-40 C to +70 CRelative humidity (non-condensing)10% to 95%MTBF123.7 years, MIL-HDBK 217F: Gb 25 CMechanical constructionDimensions (W x H x D)25 mm x 114mm x 79 mmMountingDIN Rail 35 mmWeight113 gProtection classIP 30Mechanical stabilityIEC 60068-2-27 shock15 g, 11 ms duration, 18 shocksIEC 60068-2-6 vibration3.5 mm, 3 Hz - 9 Hz, 10 cycles, 1 octave/min.;1g, 9 Hz - 150 Hz, 10 cycles, 1 octave/min.EMC interference immunityEN 61000-4-2 electrostatic discharge (ESD)6 kV contact discharge, 8 kV air dischargeEN 61000-4-3 electromagnetic field10 V/m (80 - 1000 MHz)EN 61000-4-4 fast transients (burst)2 kV power line, 4 kV data lineEN 61000-4-5 surge voltagepower line: 2 kV (line/earth), 1 kV (line/line), 1 kV data lineEN 61000-4-6 conducted immunity10 V (150 kHz - 80 kHz)EMC emitted immunityFCC CFR47 Part 15FCC CFR47 Part 15 Class AEN 55022EN 55022 Class AApprovalsSafety of industrial control equipmentcUL 508Scope of delivery and accessoriesScope of deliverydevice, terminal block, operating manualAccessories to order separatelyRail power supply RPS 30, RPS 80 EEC or RPS 120 EEC, 19" installation frameRecommended Products For Hirschmann
