Joslyn Clark Controls 5DP Definite Purpose DC Contactor
Joslyn Clark Controls
Product Code: 5DP Definite Purpose
Brand: Joslyn Clark Controls
GET OFFER: info@imtek.com.tr
Description for Joslyn Clark Controls 5DP Definite Purpose DC Contactor
5DP Definite Purpose DC Contactors are designed for DC adjustable speed drive circuits using silicon controlled rectifier switching and other controls where a combination of normally open and normally closed power contacts are required. In all applications, reduced panel space for dc contactor mounting is made possible through a compact design and the built-in N.C. dynamic brake power contact feature. In silicon controlled rectifier switching circuits, the SCR is normally phased back prior to contactor opening. Therefore, the N.O. contacts are not required to interrupt any appreciable current. Under abnormal conditions such as failure of the SCR or the control circuit, the dc contactor may be required to interrupt up to 200% current. The N.O. contacts are equipped with permanent magnet blowouts to meet this requirement. The dynamic brake N.C. contact is required to insert the dynamic brake resistor and therefore must make up to 200% of rated current each time the dc contactor is de-energized. Jogging is accomplished at low voltage and current. Therefore, the dynamic brake contact is rated at 1/3 of rated voltage and dynamic brake current. The permanent magnet blowouts provide this interrupting ability.Recommended Products For Joslyn Clark Controls
