JVM JDA 30-50 Dosing Drive

JVM

Product Code: JDA 30-50
Brand: JVM



GET OFFER: info@imtek.com.tr

Description for JVM JDA 30-50 Dosing Drive

Discover more about JVM® Dosing DrivesDosing Drives Series JDJVM® dosing drives generate only little noise, are main-tenance-free and have naturally been designed for con-tinuous operation. The tried-and-tested engineering and the compact, minimised dead point construction in protection system IP65 ensures operational reliability and easy cleaning.The electromagnetic drives generate linear oscillations and are operated via Thyristor controllers.JD dosing drives are ideal for dosing, mixing and feed-ing applications in the packaging, weighing and automa-tion industries, at low to medium throughput rates.The oscillation amplitude can be infinitely adjusted dur-ing operation via the controller. The conveying speed can thus be adjusted from standstill up to the maximum performance via potentiometer or target value.In order to obtain the optimum vibration parameters, even under varying influences of the conveyed material, every drive unit is tuned in our workshop to the effective weight required by your application.The drives are also ideal for clock cycle operation be-cause the drive reaches maximum oscillation amplitude as soon as it is started and it comes to a stop immedi-ately after being switched off.JVM® dosing drives generate only little noise, are main-tenance-free and have naturally been designed for con-tinuous operation. The tried-and-tested engineering and the compact, minimised dead point construction in pro-tection systemIP65 ensures operational reliability and easy cleaning.Using several drive units on one machine allows for longer conveying routes, and/or higher design weights.Please note that dosing drives are operated via a thyristor controller. Please use only the specified moving-iron instruments for measuring the current. Centre of gravity The centre of gravity of the trough top fixture must be situated on the X-X line for all types. The dimension “K” states the intersection with the bearing surface.
