Kirchgaesser TEM-EX-C Temperature Transducer
Product Code:TEM-EX-C
Description
Measuring ranges:Selectable in the range of -20...+150 °C acc. to the table of versionsOther measuring ranges are available on request!Electrical connection:Hirschmann connector type G4Sensor length:Standard: 100 mm, 160 mm, 230 mm, 360 mm and 510 mmOther sensor length are available on request!Output signal:Provided by the Kirchgaesser evaluation and/or display unit COMBA-EXProcess connection, sensor:Thread G½Selectable length of sensorHousing:Stainless steelConnector: PlasticPower supply:Provided by the Kirchgaesser evaluation and/or display unit COMBA-EXNennstrom:ca. 2 mAProtection acc. to EN 60529:IP 65Marking acc. to 2014/34/EU (ATEX):I M1 Ex ia I (KDB 08ATEX209)Ambient temperature:-20...+70 °CProcess temperature:-20...+150 °CMeasuring uncertainty:Max. ± 0.2 K from measurement value (upper range value ? +60 °C)Max. ± 0.5 % of end value (+60 °C < upper range value)
Technical Specifications
| Measuring ranges: |
|
| Electrical connection: | Hirschmann connector type G4 |
| Sensor length: |
|
| Output signal: | Provided by the Kirchgaesser evaluation and/or display unit COMBA-EX |
| Process connection, sensor: |
|
| Housing: |
|
| Power supply: | Provided by the Kirchgaesser evaluation and/or display unit COMBA-EX |
| Nennstrom: | ca. 2 mA |
| Protection acc. to EN 60529: | IP 65 |
| Marking acc. to 2014/34/EU (ATEX): | I M1 Ex ia I (KDB 08ATEX209) |
| Ambient temperature: | -20...+70 °C |
| Process temperature: | -20...+150 °C |
| Measuring uncertainty: |
|
