Ropex RES-402/230VAC Temperature Controller
| 브랜드 |  |
| 카테고리 | 컨트롤러 |
| 제품명 | Ropex RES-402/230VAC Temperature Controller |
| 제품 코드 | RES-402/230VAC |
저희에게 연락하세요! 영업일 기준 24시간 이내(주말 및 공휴일 제외) 재고 상태와 예상 납기를 안내해 드립니다.
제품 설명
Ropex의 Ropex RES-402/230VAC Temperature Controller을(를) 포함한 제품은 병행 수입 채널을 통해 조달되며 United States의 고객에게 신속하고 안정적으로 배송됩니다. Imtek Engineering은 경쟁력 있는 가격으로 정품 Ropex 부품을 제공합니다. Ropex RES-402/230VAC Temperature Controller이 당사 웹사이트에 등록되어 있지 않더라도 언제든지 견적을 요청하실 수 있으며, 담당 팀이 신속히 답변 드릴 것입니다.
United StatesTechnical data
9
Technical data
Type of construction
Housing for installation in the electrical cabinet Snaps onto a standard top hat rail (DIN TS35 rail, 35mm) acc. to DIN EN 50022
Dimensions: 90 x 75mm; height: 135mm (incl. terminals)
Line voltage
All controllers manufactured as of January 2006:
115VAC version: 110VAC -15%…120VAC +10% (equivalent to 94…132VAC) 230VAC version: 220VAC -15%…240VAC +10% (equivalent to 187…264VAC)
400VAC version: 380VAC -15%…415VAC +10% (equivalent to 323…456VAC) All controllers manufactured up to December 2005:
115VAC version: 115VAC -15%…120VAC +10% (equivalent to 98…132VAC) 230VAC version: 230VAC -15%…240VAC +10% (equivalent to 196…264VAC)
400VAC version: 400VAC -15%…415VAC +10% (equivalent to 340…456VAC) Depending on the controller version ( section 12 "How to order" on page 31)
Line frequency
47…63Hz, automatic adjustment to frequencies in this range
Auxiliary voltage Terminals 14+13
24VDC, +20%, -10%, reverse polarity-protected Current input: max. 1.0A
Heatsealing band type and temperature range
Default value 300°C, Alloy A20
Analog input (set point) Terminals 15+12
0…10VDC, Imax = 5mA, electrically isolated Equivalent to 0…300°C or with an external PD-3 precision potentiometer (R = 2kohms)
0…2kohms equivalent to 0…300°C
Analog output (actual value) Terminals 11+12
0…10VDC, Imax = 5mA, electrically isolated Equivalent to 0…300°C Accuracy: ±1% add. 50mV
Reference voltage
+10VDC / ±5%, Imax = 5mA
Digital logic levels Terminals 16, 17, 18
LOW (0V): 0…2VDC, electrically isolated
HIGH (24VDC): 12…30VDC (max. current input 6mA) Reverse polarity-protected
Alarm output
UON < 3V (saturation voltage), Imax = 200mA, electrically isolated, short-circuit proof
Maximum load (primary current of impulse transformer)
Imax = 5A (duty cycle = 100%) Imax = 25A (duty cycle = 20%)
Power dissipation
max. 20W
Ambient temperature
+5…+45°C
Degree of protection
IP20
Version 1
RES-402
Page 29
9
Technical data
Type of construction
Housing for installation in the electrical cabinet Snaps onto a standard top hat rail (DIN TS35 rail, 35mm) acc. to DIN EN 50022
Dimensions: 90 x 75mm; height: 135mm (incl. terminals)
Line voltage
All controllers manufactured as of January 2006:
115VAC version: 110VAC -15%…120VAC +10% (equivalent to 94…132VAC) 230VAC version: 220VAC -15%…240VAC +10% (equivalent to 187…264VAC)
400VAC version: 380VAC -15%…415VAC +10% (equivalent to 323…456VAC) All controllers manufactured up to December 2005:
115VAC version: 115VAC -15%…120VAC +10% (equivalent to 98…132VAC) 230VAC version: 230VAC -15%…240VAC +10% (equivalent to 196…264VAC)
400VAC version: 400VAC -15%…415VAC +10% (equivalent to 340…456VAC) Depending on the controller version ( section 12 "How to order" on page 31)
Line frequency
47…63Hz, automatic adjustment to frequencies in this range
Auxiliary voltage Terminals 14+13
24VDC, +20%, -10%, reverse polarity-protected Current input: max. 1.0A
Heatsealing band type and temperature range
Default value 300°C, Alloy A20
Analog input (set point) Terminals 15+12
0…10VDC, Imax = 5mA, electrically isolated Equivalent to 0…300°C or with an external PD-3 precision potentiometer (R = 2kohms)
0…2kohms equivalent to 0…300°C
Analog output (actual value) Terminals 11+12
0…10VDC, Imax = 5mA, electrically isolated Equivalent to 0…300°C Accuracy: ±1% add. 50mV
Reference voltage
+10VDC / ±5%, Imax = 5mA
Digital logic levels Terminals 16, 17, 18
LOW (0V): 0…2VDC, electrically isolated
HIGH (24VDC): 12…30VDC (max. current input 6mA) Reverse polarity-protected
Alarm output
UON < 3V (saturation voltage), Imax = 200mA, electrically isolated, short-circuit proof
Maximum load (primary current of impulse transformer)
Imax = 5A (duty cycle = 100%) Imax = 25A (duty cycle = 20%)
Power dissipation
max. 20W
Ambient temperature
+5…+45°C
Degree of protection
IP20
Version 1
RES-402
Page 29
