Koso 3620R/210C Concentric Segmental Ball Valves
Koso
Product Code: 3620R/210C
Brand: Koso
GET OFFER: info@imtek.com.tr
Description for Koso 3620R/210C Concentric Segmental Ball Valves
210C: Concentric Segmental Ball Valves (FLOWMAX C/Wafer)220C: Concentric Segmental Ball Valves (FLOWMAX C/Flanged)230C: Concentric Segmental Ball Valves210C: Concentric Segmental Ball Valves (FLOWMAX C/Wafer)This series is concentric segmental ball valve for modulating application. V-notch cut at disc makes rangeability larger and creates shearing effect by disc and seal ring. Therefore, suitable to large rangeability service and/or control of fluids with fiber and/or slurry.230C: Concentric Segmental Ball ValvesThis series is same as 210C series except that the stem penetrates the body and is supported by double gland packing.The stem's blow out force is set off in this construction making it suitable to heavier services such as high pressure, high temperature service because of heat expansion insulation design stem.SpecificationsBody type210C220C230CBody size1"(25A) to 12"(300A)1"(25A) to 18"(450A)6"(150A) to 24"(600A)Body ratingANSI Class 150 to 600, JIS 10K to 40KJIS 10KANSI Class 150 to 1500, JIS 20K to63KFluid temperature-45 to +500°-45 to +500°-45 to +650°ConnectionsWafer typeFlanged (RF)Flanged (RF, RTJ)Body materialsSCPH2/WCB, SCS13A/CF8, SCS14A/CF8M. etc.Disc materialsSCS14ASCS13A, SCS14ADisc treatmentChrome plated or StellitedSeal ring materialsR.TFE, SUS316R.TFE, SUS304, 316Rangeability100:1 to 500:1100:1Flow characteristicsApproximate Eq% (Inherent Characteristic)LeakageMetal seatL Type seat: Rated Cv × 0.001%H Type seat: Rated Cv × 0.25%Soft seatBubbletight ANSI Class VIActuator combination6300RB, 6400RB, 6500RA, 7300RA: Pneumatic Cylinder Actuator3500RB, 3600RB: Solid State Electronic Actuator3400RB: Electric Motor ActuatoRecommended Products For Koso
