SICK 1056428 type: S30B-3011CA Safety Laser Scanner

Technical Documentation

기술 데이터시트 / 제품 문서

  • 현재 이 제품에 대한 기술 문서가 없습니다. 자세한 정보는 문의해 주세요.
WhatsApp
브랜드
SICK logo - Official brand
카테고리기타
제품명SICK 1056428 type: S30B-3011CA Safety Laser Scanner
제품 코드S30B-3011CA
Visa – Secure credit card payment acceptedMastercard – Secure credit card payment acceptedAmerican Express – Secure credit card payment acceptedDiners Club – Secure credit card payment acceptedDiscover – Secure credit card payment accepted

저희에게 연락하세요! 영업일 기준 24시간 이내(주말 및 공휴일 제외) 재고 상태와 예상 납기를 안내해 드립니다.

제품 설명

SICK의 SICK 1056428 type: S30B-3011CA Safety Laser Scanner을(를) 포함한 제품은 병행 수입 채널을 통해 조달되며 United States의 고객에게 신속하고 안정적으로 배송됩니다. Imtek Engineering은 경쟁력 있는 가격으로 정품 SICK 부품을 제공합니다. SICK 1056428 type: S30B-3011CA Safety Laser Scanner이 당사 웹사이트에 등록되어 있지 않더라도 언제든지 견적을 요청하실 수 있으며, 담당 팀이 신속히 답변 드릴 것입니다.

  • FEATURES
    Protective field range3 m
    Warning field range8 m (at 15 % reflectivity)
    Distance measuring range30 m
    Type of field setTriple field sets
    Number of field sets4
    Number of fields12
    Number of monitoring cases4
    Scanning angle270°
    Resolution (can be configured)30 mm, 40 mm, 50 mm, 70 mm, 150 mm
    Angular resolution0.5°
    Response time80 ms 1)
    Protective field supplement100 mm
    Number of multiple samplings2 ... 16, configurable
    Delay of automatic reset2 s ... 60 s, configurable
    • 1) Depending on basic response time and multiple sampling.
  • SAFETY-RELATED PARAMETERS
    TypeType 3 (IEC 61496)
    Safety integrity level

    SIL2 (IEC 61508)

    SILCL2 (EN 62061)

    CategoryCategory 3 (EN ISO 13849)
    Performance levelPL d (EN ISO 13849)
    PFHD (mean probability of a dangerous failure per hour)8.0 x 10-8 (EN ISO 13849)
    TM (mission time)20 years (EN ISO 13849)
    Safe state in the event of a faultAt least one OSSD is in the OFF state.
  • FUNCTIONS
    Restart interlock✔
    External device monitoring (EDM)✔
    Multiple sampling✔
    Monitoring case switching✔
    Static protective field switching✔
    Contour as a reference✔
    Integrated configuration memory✔
    Measured data output✔ , Via RS-422
    Safe SICK device communication via EFI✔
  • INTERFACES
    Connection typeSystem plug with or without connecting cable
    Universal I/Os​5 1)
    Inputs
    External device monitoring (EDM)1 2)
    Reset/restart1 2)
    Static control inputs2
    Static control inputs with EFI5 3)
    Standby1
    Outputs
    OSSD pairs1
    Application diagnostic outputs3 4)
    Configuration methodPC with CDS (Configuration and Diagnostic Software)
    Configuration and diagnostics interfaceRS-232
    Transmission rate38.4 kBaud
    Data interfaceRS-422
    Transmission rate≤ 500 kBaud
    Safe SICK device communication via EFI
    Transmission rate≤ 500 kBaud
    Length of cable≤ 50 m
    Conductor cross-section0.22 mm²
    Fieldbus, industrial network
    Integration via EFI gatewaysCANopen 5)
    Ethernet
    PROFIBUS DP
    PROFIBUS PROFIsafe
    PROFINET PROFIsafe
    • 1) Freely programmable, e.g., external device monitoring input, reset input, contamination warning, reset required.
    • 2) Availability depends on the configuration of the universal I/Os.
    • 3) In combination with an EFI device (Flexi Soft or EFI gateway) five static control inputs are available. Otherwise two.
    • 4) Freely programmable, e.g. warning field, contamination, reset required.
    • 5) For a suitable EFI-gateway see modules and gateways in the accessory section of connection systems.
  • ELECTRICAL DATA
    Protection class

    III (EN 50178)

    EN 60950

    Supply voltage Vs24 V DC (16.8 V DC ... 30 V DC)
    Power consumption

    ≤ 0.33 A 1)

    ≤ 1.7 A 2)

    Outputs
    Output signal switching devices (OSSDs)2 x 250 mA
    Application diagnostic outputs3 x 100 mA 3)
    • 1) At 24 V DC without output load.
    • 2) At 24 V DC including maximum output load.
    • 3) Freely programmable, e.g. warning field, contamination, reset required.
  • MECHANICAL DATA
    Dimensions (W x H x D)102 mm x 152 mm x 106 mm
    Weight1.2 kg
    Housing materialAluminum die cast
    Housing colorRAL 1021 (yellow)
    Optics cover materialPolycarbonate
    Optics cover surface finishOutside with scratch-resistant coating
  • AMBIENT DATA
    Enclosure ratingIP65 (EN 60529)
    Ambient operating temperature–10 °C ... +50 °C
    Storage temperature–25 °C ... +50 °C
    Vibration resistance

    5 g, 10 Hz ... 150 Hz (IEC 61496)

    IEC 61496-3

    Shock resistance
    Continuous shock10 g, 16 ms (IEC 61496)
    IEC 61496-3
  • OTHER INFORMATION
    Type of lightPulsed laser diode
    Wave length905 nm
    Detectable remission1.8 % ... > 1,000 %, reflectors
    Laser class1 (21 CFR 1040.10 and 1040.11, IEC 60825-1)
  • CLASSIFICATIONS
    ECl@ss 5.027272705
    ECl@ss 5.1.427272705
    ECl@ss 6.027272705
    ECl@ss 6.227272705
    ECl@ss 7.027272705
    ECl@ss 8.027272705
    ECl@ss 8.127272705
    ECl@ss 9.027272705
    ECl@ss 10.027272705
    ECl@ss 11.027272705
    ETIM 5.0EC002550
    ETIM 6.0EC002550
    ETIM 7.0EC002550
    UNSPSC 16.090139121528
