Lamtec 662R5009 Servomotor

Lamtec

Product Code: 662R5009
Brand: Lamtec



GET OFFER: info@imtek.com.tr

Description for Lamtec 662R5009 Servomotor

Function 662R5001... 662R5003... 662R5009... Power supply 24VDC ±20% Floating time 5 s/90° 5 s/90° 15 s/90° Direction of rotation 0° to 90° left - view to the drive shaft Effective output torque 1.2 Nm (both directions of rota- tion) 3 Nm (both directions of rota- tion) 9 Nm (both directions of rotation) Holding torque 0.82 Nm (currentless) 2.8 Nm (currentless) 6 Nm (currentless) Permissible radial load   100 N (centre of output shaft) Permissible axial load 10 N Axial play of drive shaft 0.1.... 0.2 mm 0.1.... 0.2 mm   Motor RDM 51/6 stepper motor Angular resolution 0.1°/motor step 0.1°/motor step 0.03°/motor step Rated resolution encoder monitoring   0,7° Monitoring accuracy ± 0,5° ± 0,5° ± 1.3125° (corresponds 44 motor steps) Repeat accuracy ± 0,1° ± 0,1° ± 0,1° Life cycle 2,000,000 motions forward and back performed on complete actuator range Degree of protection IP54 according to DIN EN 60529-1 Weight 1400 g Cable length securely connected 1.5mpluggable max. 3 m securely connected 1.5mpluggable max. 3 m pluggable max. 3 m
