Lamtec GKI300 Graphic Customer Interface

Lamtec

Product Code: GKI300
Brand: Lamtec



GET OFFER: info@imtek.com.tr

Description for Lamtec GKI300 Graphic Customer Interface

Voltage supply: 230 VAC +10 % -15 % 50/60 Hz 115 VAC +10 % -15 % 50/60 Hz (option) Ambient temperature Operation: +0 °C … +60 °C Ambient temperature Transport and storage: -25 °C … +60 °C Resolution per analogue input: 999 digit, 10 bit Three-point-step: Via external relay modules type 660R0013 up to 50 mA (40 Nm) type 660R0131 more than 30 Nm up to 3,1 A Recommended run time of the servomotor: 30 s … 60 s Constant outputs 0 … 10 V > 5 k? Load: 0/4 … 20 mA < 600 ? Digital signal inputs: 16 via floating contact 24 VDC Number of curve-sets: 2 per channel (e.g. for oil/gas dual-fuel burner) optional 4 or 8 BUS connection: Via 25-pole sub-D socket, communication processor optional for the systems: ·        Interbus-S (Phoenix) ·        PROFIBUS ·        Modbus ·        CANopen
