Micro Detectors BX10R/AD-HB6A Area Sensor Image

Micro Detectors BX10R/AD-HB6A Area Sensor

Micro Detectors

Product Code: BX10R/AD-HB6A
Brand: Micro Detectors



GET OFFER: info@imtek.com.tr

Description for Micro Detectors BX10R/AD-HB6A Area Sensor

Detection propertiesNominal sensing distance0,3 … 6mThermal drift of Sr?10%Beams space10mmcontrolled height90mmminimum detectable objectØ 5mmnumber of rays10Sensitivity adjustmentTrimmerApplicationFunction PrincipleReceiverOutputsOutput typeNPN + PNPOutput FunctionNOSwitching frequency110HzResposnse time for light/dark transition800µsResposnse time for dark/light transition8msElectrical dataOperating Voltage10 - 26VdcNo-Load supply current50mALoad current?100mALeakage current10?AOutput voltage drop?2V IL =100 mAMax ripple content? 10%LED indicatorsRed, YellowTime delay before availabilityCEShort-circuit protectionautoresetReverse Polarity ProtectionYesEmissionInfraredInterference to external light1000lux (incandescent lamp),1500lux (sunlight)Impulsive Overvoltage ProtectionYesMechanical dataDimensions45mm x 145mm x 20mmWeight230gHousing MaterialPBTConnectionsM12 PlugTightening torque25NmOperating temperature0°C…+ 50° C (without freeze)Test/ApprovalsApprovalsCEEMC compatibilityEN 60947-5-2Degree of protectionIP67AccessoriesSupplied Accessories4 nuts M18x1 - 1 adjustment key - 2 90°angled brackets
