Micro Detectors BX80A/1P-1H Area Sensor

Micro Detectors

Product Code: BX80A/1P-1H
Brand: Micro Detectors



GET OFFER: info@imtek.com.tr

Description for Micro Detectors BX80A/1P-1H Area Sensor

Detection propertiesNominal sensing distance0 … 2mThermal drift of Sr?10%Beams space6mmcontrolled height70mmminimum detectable objectØ 6mmnumber of rays12ApplicationFunction PrincipleReceiverOutputsOutput typePNPOutput FunctionNO/NCSwitching frequency10msElectrical dataOperating Voltage12 - 24VdcNo-Load supply current50mALoad current?100mALeakage current10µAOutput voltage drop?1.2V IL =100 mAMax ripple content? 10%LED indicatorsgreen (supply), red (alignment), yellow (output state)Time delay before availability500msShort-circuit protectionYes (auto reset)Reverse Polarity ProtectionYesEmissionInfrared (880 nm)Interference to external light1.500 lux max. (incandescent lamp), 4.500 lux max. (sunlight)Impulsive Overvoltage ProtectionYesMechanical dataDimensions60mm x 132mm x 30mmWeight260 … 300gHousing MaterialPBTConnectionsM12 plugActive Head MaterialPCTightening torque25NmOperating temperature-25°C…+50°C (without freeze)Storage temperature-40°C…+80°CTest/ApprovalsApprovalsCEEMC compatibilityIEC 60947-5-2Shocks and vibrationsIEC EN 60947-5-2Degree of protectionIP67
