Micro Detectors BX80S/10-1HDA Area Sensor
Micro Detectors
Product Code: BX80S/10-1HDA
Brand: Micro Detectors
GET OFFER: info@imtek.com.tr
Description for Micro Detectors BX80S/10-1HDA Area Sensor
Detection propertiesNominal sensing distancedepending on the receiverThermal drift of Sr?10%Beams space6mmcontrolled height70mmminimum detectable objectDepending onthe receivernumber of rays12Sensitivity adjustmentYesApplicationFunction PrincipleEmitterOutputsOutput typeEmitterOutput FunctionEmitterSwitching frequency10msElectrical dataOperating Voltage12 - 24VdcNo-Load supply current100mALoad current?100mALeakage current10µAOutput voltage drop?1.2V IL =100 mAMax ripple content? 10%LED indicatorsgreen (supply), red (alarm sync.), yellow (area state)Time delay before availability500msShort-circuit protectionYes (auto reset)Reverse Polarity ProtectionYesEmissionInfrared (880 nm)Interference to external light1.500 lux max. (incandescent lamp), 4.500 lux max. (sunlight)Impulsive Overvoltage ProtectionYesMechanical dataDimensions60mm x 132mm x 30mmWeight260 … 300gHousing MaterialPBTConnectionsM12 plugActive Head MaterialGlassTightening torque25NmOperating temperature-25°C…+50°C (without freeze)Storage temperature-40°C…+80°CTest/ApprovalsApprovalsCEEMC compatibilityIEC 60947-5-2Shocks and vibrationsIEC EN 60947-5-2Degree of protectionIP67Recommended Products For Micro Detectors
