Micro Detectors C30M/00-2A Proximity Sensor

Micro Detectors

Product Code: C30M/00-2A
Brand: Micro Detectors



GET OFFER: info@imtek.com.tr

Description for Micro Detectors C30M/00-2A Proximity Sensor

Detection propertiesNominal sensing distance4…25mmThermal drift of Sr< 20%Repeat Accuracy5%Sensitivity adjustmentYesHysteresis? 20%OutputsOutput typeSCROutput FunctionNO/NC selectableSwitching frequency10HzElectrical dataOperating Voltage20...250Vac/50-60HzNo-Load supply current? 12mALoad current2,5A max (20ms)Leakage current? 100µAOutput voltage drop10VAC @ IL?200mAMax ripple content?10%LED indicatorsYellow LED (object detected)Time delay before availability? 200msShort-circuit protectionYes, autoresetReverse Polarity ProtectionYesImpulsive Overvoltage ProtectionYesMechanical dataMountingUnshieldedDimensionsM30 / L = 91mmWeight230gHousing MaterialAISI 304 stainless steelConnections2m PVC cableActive Head MaterialPolyesterTightening torque50NmOperating temperature-25°C…+80°C (without freeze)Storage temperature-40°C…+85°CDiameter/DimensionM30Test/ApprovalsApprovalsCE cULusEMC compatibilityIEC 60947-5-2Shocks and vibrationsVibration IEC 60068-2-6 / Shock IEC 60068-2-27Degree of protectionIP67AccessoriesSupplied Accessoriesscrew driver, 2 x M30 nuts
