Moog G761-3003B Servo Valve
Technical Datasheets / Product Documentations
| Brand |  |
| Category | Valve |
| Product Name | Moog G761-3003B Servo Valve |
| Product Code | G761-3003B |
Contact with us! 24 business hours (excluding weekends and holidays) to confirm stock status and estimated delivery time.
Product Description
Moog products, including Moog G761-3003B Servo Valve, are sourced through parallel import channels and delivered to our customers worldwide with speed and reliability. As an authorized trading partner, Imtek Engineering offers genuine Moog parts at competitive prices. Even if Moog G761-3003B Servo Valve is not listed on our website, you are welcome to request a price quote — our team will respond promptly with a tailored offer.
Moog 761 Series Flow Control Servo Valves
761 SERIES SERVO VALVES General Technical Data Valve design
2-stage mechanical feedback, with bushing and spool
Pilot valve
Nozzle flapper
Mounting pattern
ISO 10372-04-04-0-92
Installation position
Any position, fixed or movable
Weight with steel body
1.7 kg (3.8 lb)
Weight with aluminium body
1.0 kg (2.2 lb)
Storage temperature range
-40 to +60 °C (-40 to +140 °F)
Ambient temperature range
-29 to +135 °C (-20 to +275 °F) 1)
Vibration resistance
30 g, 3 axis, 10 Hz to 2 kHz
Shock resistance
30 g, 3 axis
1) Option available for higher temperature ranges up to 400 °F.
Hydraulic Data 1) Maximum operating pressure port P, X, A, B
•
Aluminium body: 315 bar (4,500 psi)
•
Steel body: 350 bar (5,000 psi)
Maximum operating pressure port T
Static: same as P port. Normal operating: 70 bar (1,000 psi).
Minimum operating pressure
14 bar (200 psi)
Rated flow at ΔpN 35 bar (500 psi)/spool land
0.5 to 2 l/min 4 l/min 10 l/min (0.13 to 0.53 gpm) (1.1 gpm) (2.5 gpm)
Maximum flow Qmax
104 l/min (27.5 gpm)
Typical leakage
1.0 l/min (0.26 gpm)
1.5 l/min (0.4 gpm)
Maximum total leakage (axis cut)
1.2 l/min (0.31 gpm)
2 l/min 2.8 l/min 3 l/min (0.79 gpm) (0.53 gpm) (0.74 gpm)
Pilot flow
0.45 l/min (0.12 gpm) to 0.80 l/min (0.21 gpm)
Null adjust authority
2)
75 %
19 l/min (5 gpm)
38 l/min (10 gpm)
57/63 l/min 75 l/min (15.1/16.6 gpm) (19.8 gpm)
2.1 l/min (0.55 gpm)
60 %
25 %
15 %
3.3 l/min (0.87 gpm) 10 %
Hydraulic fluid
Mineral oil based fluids according to DIN 51524 parts 1 to 3 and ISO 11158. Other
fluids upon request.
Seal material
FKM (fluorocarbon) 90 Shore, EPR (ethylene-propylene copolymer) 90 Shore,
others upon request
Hydraulic fluid temperature range
-29 to +135 °C (-20 to +275 °F)
Recommended viscosity range at 38 °C (100 °F)
15 to 100 mm2/s (cSt)
Recommended cleanliness class as per ISO 4406 for functional safety
17/14/11
Recommended cleanliness class as per ISO 4406 for longer service life
15/13/10
Recommended filter rating for functional safety
ß10 ≤ 75 (10 μm absolute)
Recommended filter rating for longer service life
ß5 ≤ 75 (5 μm absolute)
1) Measured at 210 bar (3,000 psi) pilot or operational pressure, oil viscosity 32 mm2/s and oil temperature +40 °C (+104 °F)
2) For standard configuration. Optional magnetic null offers approximately 10 % adjustment.
Rev. M, April 2024
6
