Mts Sensor MT 551218 Positions Sensor
Mts Sensor
Product Code: MT 551218
Brand: Mts Sensor
GET OFFER: info@imtek.com.tr
Description for Mts Sensor MT 551218 Positions Sensor
InputMeasured variables: DisplacementMeasuring range: 50 - 2500 mm in 5 mm stepsOutputSignal characteristic: Continuously analog output restricted by noise or A/D converter of control unitVoltage: 0.25...4.75 VDC0.5...4.5 VDCCurrent: 4...20 mAinverse: 4.75...0.25 VDCinverse: 4.5...0.5 VDCinverse: 20...4 mAResolution: typ ± 0.1 mmInternal Cycle Time: 2 msAccuracyLinearity: .1 mmHysteresis: ± 0.1 mmSetpoint Tolerance: ? 1 mmOperating conditionsAssembly orientation: In any directionOperating temperature electronics, storage temp.: -40°C...+105°CFluid temperature: -30°C...+85°CDew point, humidity: 90 % rel. humidity, no condensation acc. EN60068-2-30PressureOperating pressure ratings:Pressure impulse test acc.Ø 10 mm sensor rodPN: 350 barPmax: 450 bar DIN EN ISO 19879IP rating sensor housingSensor housing: IP67, EN60529Environmental testing:Shock:Vibration:EMC:IEC-68-2-27100 g (6 ms) single hit50 g (11 ms) at 1000 Shocks per axisIEC 68-2-6 (10...2000 Hz)Ø 10 mm sensor rod 15g (r.m.s)ISO 14982 agricultural and forestry machinesISO 11452-2 (radiated immunity) (Increased immunity voltage output 100V/m)ISO 11452-4 (conducted immunity)ISO 7637-1/2 (transient Impulses)Materials and dimensionsSensor rod:Housing:Mechanical assembly:Stainless steel 1.4306 / AISI 304L (Ø 10 mm)Stainless steel 1.4305 / AISI 303Flange housing Ø 48 mmO-ring 40.87 x 3.53 mm NBR 80, backup ring 42.6 x 48 x 1.4 PTFEElectrical installationConnector:Supply voltage:Voltage supply ripple:Power drain:Electric strength:Over voltage protection (GND - VDC):Polarity protection (GND - VDC):Load:Connector System 2 x M12x1 with O-ring 7 x 1.35 mm NBR 70Connecting flange brass nickel-plated with O-ring 13 x 1.6 NBR 7012/24 VDC (tolerance range 8 - 32 VDC)< 1 % PP< 1 W500 VDC (DC ground to machine ground)+ 36 VDCup to -36 VDCRL? 10 k? mA outputRL? 250 ? (12 VDC) VDC outputRL? 500 ? (24 VDC) VDC outputRecommended Products For Mts Sensor
