Pavone Sistemi DAT 400 Profinet Weight Transmitters
Pavone Sistemi
Product Code: DAT 400
Brand: Pavone Sistemi
GET OFFER: info@imtek.com.tr
Description for Pavone Sistemi DAT 400 Profinet Weight Transmitters
Technical SpecificationsMeasuring range: -0.5 ÷ +3.5 mV/V (-3.9 ÷ +3.9 mV/V optional)Input sensitivity: 0.02 µV/countFull scale non-Linearity: < 0.01%Gain drift: < 0.001% FS/°CDisplay: 6 digit, red LED (7 segments), h 14 mmA/D Converter: 24 bitInternal Resolution: > 16.000.000 pointsTrasducer input voltage: 5 V (max 6 load cells 350 Ohm)Visible resolution (in divisions): 60000Divisions value (adjustable): x1, x2, x5Decimal figures range: 0 ÷ 3Temperature range: -10 ÷ +50°C (max umidity 85% without condensation)Storage temperature: -20 ÷ +70 °CFilter: 0.1 ÷ 25 HzLogic output: 2 Solid-state relays, (maximum load 24 Vdc / 100 mA each)Logic input: 2 optoisolated 24 Vdc PNP (External voltage)Serial port: Nr. 2 - USB/RS232C, RS422/485 with ASCII or Modbus RTU protocolsPower supply: 24 Vcc ±15% - power 5 WRegulatory compliance: EN61326-1, EN55011, EN55014 for EMC; EN61010-1 for electrical securityDimensions and weight: 106 x 90 x 58 mm (L x H x P); 250 gBaud rate: 2400, 9600, 19200, 38400, 115200 adjustable (RS232)Transmission distance: 15m (RS232C), 1000m (RS422; RS485)Recommended Products For Pavone Sistemi
