Ringfeder TNZ ZCAF/TNZ ZCBF Gear Coupling

Ringfeder

Product Code: TNZ ZCAF/TNZ ZCBF
Brand: Ringfeder



GET OFFER: info@imtek.com.tr

Description for Ringfeder TNZ ZCAF/TNZ ZCBF Gear Coupling

Intermediate shaft and rigid counter-?anges The model RINGFEDER® TNZ ZCAF is composed from the coupling halves of the coupling TNZ ZCA and is complemented by an intermediate shaft and two rigid counter-?anges. If required, the torsional stiffness of the shaft can be tuned to the dynamic behavior of the drive line. In addition, the intermediate shaft, which serves to accommodate longer shaft separations, can be mounted and dismounted radially with- out having to move the connected machines.The model RINGFEDER® TNZ ZCBF is composed from the coupling halves of the coupling TNZ ZCB and is complemented by an intermediate shaft and two rigid counter-?anges. If required, the torsional stiffness of the shaft can be tuned to the dynamic behavior of the drive line. In addition, the intermediate shaft, which serves to accommodate longer shaft separations, can be mounted and dismounted radially without having to move the connected machines.Characteristics General features Torsionally rigid gear coupling made of high-quality steel Very compact design results in a high-power density Compensates for angular, radial and axial shaft offset Suitable for use in temperatures up to +120 °C if special seals are used Available with split sleeve (ZCA / ZCB - ZCA model range also available in ZCB design) and single-piece sleeve (ZCH) The elastic O-Ring can be replaced without having to move the coupled machines Bores up to 270 mm Torques up to TKn = 195,000 Nm / TKmax = 390,000 Nm Speeds up to nmax = 6,000 rpm General description The RINGFEDER® TNZ coupling is a torsionally rigid twin cardanic gear coupling. Toothing The coupling housings have a straight internal toothing whilst the hubs have an external toothing with a chased variable radius. As a result, the hubs can move spatially within the housing and thus compensate angular, radial and axial shaft misalignment of the adjoined shaft ends within specified tolerances. Depending on coupling type and size, the standard toothing permits an angular misalignment of up to 0.5 degrees per toothing-plane and an axial movement of several millimetres. The max. possible radial shaft displacement is dependent on the distance between the two toothing planes. Other toothing geometries can be used for further specific applications. Materials High-grade tooth profiles and grease with ultra high-pressure additives guarantee low-restoring forces and a long serviceable life. The material used is forged steel with an apparent yielding point of at least 335 N/mm2. Special materials can be used for further specific applications. Sealing is carried out using O-Rings of synthetic rubber. The housings are centred and held together by fit-bolts and self-locking nuts. Temperature The use of special seals permits the temperature limit to be raised to 120 °C. Balance At peripheral speeds upwards of 30 m/s it is advisable to dynamically balance the coupling. Special applications If greater misalignments are anticipated at higher speeds and torques, an examination is necessary, performed with the assistance of a special computing programme. This is independent of the determined size. The value TKmax may not be exceeded in any state of operation (start-up, electrical short circuit, blocking, etc.). Tolerances and standards The bore tolerance is ISO H7, if not differently ordered. The bore diameters listed refer to keyways to DIN 6885-1 with wide toleranz ISO P9.
