Rotork GT Range single- and double-acting pneumatic piston actuator
Rotork
Product Code: GT
Brand: Rotork
GET OFFER: info@imtek.com.tr
Description for Rotork GT Range single- and double-acting pneumatic piston actuator
DesignSingle- and double-acting pneumatic piston actuators (rack and pinion)ActionStandard 90°, optional 120°, 180° , 240° or custom anglesStroke adjustment-5° to +5° from 90° positionSingle and double end stop optionsTorques2.4 to 15,300 Nm (135,400 lbf.in)Air pressure2 to 10 barSupplyFiltered air PNEUROP/ISO class 4, other fluids on requestMaterialsExtruded aluminium body with cast aluminium end caps – optional surface treatment availableCorrosion resistant cylinders and nickel-plated pinionApprovals and Industry StandardsCertified to ATEX 2014/34/EUCertified suitable for use at SIL3 as a single device in accordance with IEC 61508Mechanical interfaces to ISO 5211, EN 15714-3-4, NAMUR VDI / VDE 3845Recommended Products For Rotork
