Senseca HD51.3D… High-performance 2-axıs Anemometer
Senseca
Product Code: HD51.3D…
Brand: Senseca
GET OFFER: info@imtek.com.tr
Description for Senseca HD51.3D… High-performance 2-axıs Anemometer
60B2-axis ultrasonic static anemometer. Measurement of wind speed (up to 85 m/s) and direction, U-V Cartesian components of wind speed, Wind Gust, relative humidity and temperature (optional), global solar radiation (optional) and barometric pressure (optional). Isolated RS232, RS485, RS422 and SDI-12 serial outputs. NMEA, MODBUS-RTU and ASCII proprietary communication protocols. Two analog outputs for wind speed and direction, factory-configurable within 4÷20 mA (standard), 0…1 V, 0…5 V or 0…10 V (to be specified when ordering). For all models, optional function of detecting the orientation (compass) and tilt angles. Heater option available. Operating temperature -40…+70 °C. Instrument power supply 12…30 Vdc. Heater power supply 24 Vdc. Housing in thermoplastic material. Installation on mast 40 mm external and 36 mm internal. Input with 19-pole M23 male connector and 19-pole M23 female free connector. The HD52.3D-S software for instrument configuration and monitor, downloadable from Delta OHM website is included. CP51… cable on request.Recommended Products For Senseca
