Servomech ATL 30 Mechanical Linear Actuator

Servomech

Product Code: ATL 30
Brand: Servomech



GET OFFER: info@imtek.com.tr

Description for Servomech ATL 30 Mechanical Linear Actuator

Right angle design linear actuatorsRear hinged attachments. High precision worm gearbox, ZI involute profile.Lubrication with synthetic grease (gearbox long life lubricated, screw drive regreasable).ATL Series acme screw drive linear actuators:11 standard sizes availableAcme screw from Ø 13,5 mm to Ø 120 mmLinear speed from 1,4 mm/s to 140 mm/sLoad capacity from 4 kN to 600 kNStandard stroke length up to 1.000 mm, special stroke length also available upon requestPerformances with Duty Cycle Fi = 30 % over 10 min at ambient temperature 25 °C
