SICK 1028232 Type:KT10W-2P1115 Contrast sensor
Technical Datasheets / Product Documentations
- No technical documentation is available for this product at the moment. Contact us for more information.
| Brand |  |
| Category | Sensor |
| Product Name | SICK 1028232 Type:KT10W-2P1115 Contrast sensor |
| Product Code | 1028232 |
Contact with us! 24 business hours (excluding weekends and holidays) to confirm stock status and estimated delivery time.
Product Description
SICK products, including SICK 1028232 Type:KT10W-2P1115 Contrast sensor, are sourced through parallel import channels and delivered to our customers worldwide with speed and reliability. As an authorized trading partner, Imtek Engineering offers genuine SICK parts at competitive prices. Even if SICK 1028232 Type:KT10W-2P1115 Contrast sensor is not listed on our website, you are welcome to request a price quote — our team will respond promptly with a tailored offer.
- FEATURES
Dimensions (W x H x D) 30.4 mm x 53 mm x 80 mm Sensing distance 10 mm 1) Sensing distance tolerance ± 3 mm Housing design (light emission) Rectangular Light source LED, RGB 2) Wave length 640 nm, 525 nm, 470 nm Light emission Long and short side of housing, exchangeable Light spot size 0.8 mm x 4 mm Light spot direction Vertical 3) Adjustment Teach-in button Teach-in mode Static 2-point teach-in
Dynamic teach-in (min/max)
Function Automatic drift correction - 1) From front edge of lens.
- 2) Average service life: 100,000 h at TU = +25 °C.
- 3) In relation to long side of housing.
- MECHANICS/ELECTRONICS
Supply voltage 10 V DC ... 30 V DC 1) Ripple ≤ 5 Vpp 2) Power consumption < 120 mA 3) Switching frequency 25 kHz 4) Response time 20 µs 5) Jitter < 10 µs Switching output PNP Output current Imax. 100 mA Input, teach-in (ET) PNP
Teach: U = 10 V ... < UV
Run: U < 2 V
Input, blanking input (AT) PNP
Blanked: U > 10 V ... < Uv
Free-running: U < 2 V 6)
Retention time (ET) 25 ms, non-volatile memory Time delay 20 ms, adjustable Connection type Male connector M12, 5-pin Protection class II 7) Circuit protection UV connections, reverse polarity protected
Output Q short-circuit protected
Interference pulse suppression
Outputs overcurrent and short-circuit protected
Enclosure rating IP67 Weight 400 g Housing material Metal, Zinc diecast - 1) Limit values when operated in short-circuit protected network: max. 8 A.
- 2) May not exceed or fall below Uv tolerances.
- 3) Without load.
- 4) With light/dark ratio 1:1.
- 5) Signal transit time with resistive load.
- 6) AT > 200 µs.
- 7) Reference voltage DC 50 V.
- AMBIENT DATA
Ambient operating temperature –10 °C ... +55 °C Ambient storage temperature –10 °C ... +75 °C Shock load According to IEC 60068 UL File No. NRKH.E181493 & NRKH7.E181493
- CLASSIFICATIONS
ECl@ss 5.0 27270906 ECl@ss 5.1.4 27270906 ECl@ss 6.0 27270906 ECl@ss 6.2 27270906 ECl@ss 7.0 27270906 ECl@ss 8.0 27270906 ECl@ss 8.1 27270906 ECl@ss 9.0 27270906 ETIM 5.0 EC001820 ETIM 6.0 EC001820 UNSPSC 16.0901 39121528
