SICK 1057091 type: LFP2000-A4NMB Level Sensor
Technical Datasheets / Product Documentations
- No technical documentation is available for this product at the moment. Contact us for more information.
| Brand |  |
| Category | Sensor |
| Product Name | SICK 1057091 type: LFP2000-A4NMB Level Sensor |
| Product Code | LFP2000-A4NMB |
Contact with us! 24 business hours (excluding weekends and holidays) to confirm stock status and estimated delivery time.
Product Description
SICK products, including SICK 1057091 type: LFP2000-A4NMB Level Sensor, are sourced through parallel import channels and delivered to our customers worldwide with speed and reliability. As an authorized trading partner, Imtek Engineering offers genuine SICK parts at competitive prices. Even if SICK 1057091 type: LFP2000-A4NMB Level Sensor is not listed on our website, you are welcome to request a price quote — our team will respond promptly with a tailored offer.
- FEATURES
Medium Fluids Measurement Switch, Continuous Design Standard Probe type Rod probe Probe length 2,000 mm Process pressure –1 bar ... 10 bar Process temperature –20 °C ... +100 °C RoHS certificate ✔ IO-Link ✔ CULus certificate ✔
- PERFORMANCE
Accuracy of sensor element ± 5 mm 1) Reproducibility ≤ 2 mm Resolution < 2 mm Response time < 400 ms Dielectricity constant ≥ 5 for rod probe / cable probe
≥ 1.8 with coaxial tube
Conductivity No limitation Maximum level change ≤ 500 mm/s Deactivated area at process connection 25 mm 2) Deactivated area at end of probe ≥ 10 mm 1) MTTF 194.3 years (EN ISO 13849-1) - 1) With water under reference conditions.
- 2) With parameterized container with water under reference conditions, otherwise 40 mm.
- ELECTRONICS
Supply voltage 12 V DC ... 30 V DC 1) Power consumption ≤ 100 mA at 24 V DC without output load Initialization time ≤ 5 s Protection class III Connection type Round connector M12 x 1, 5-pin Output signal 4 mA ... 20 mA, 0 V ... 10 V automatic switching depending on the load. 1)
1 PNP transistor output (Q1) and 1 PNP / NPN transistor output (Q2) switchable 1)
1 x PNP + 1 x PNP/NPN + 4 mA ... 20 mA / 0 V ... 10 V
Output load 4 mA ... 20 mA < 500 Ohm at Uv > 15 V, 4 mA ... 20 mA < 350 Ohm at Uv > 12 V, 0 V ... 10 V > 750 Ohm at Uv 14 ≥ V Hysteresis Min. 2 mm, free adjustable Signal voltage HIGH Vs - 2 V Signal voltage LOW ≤ 2 V Output current < 100 mA Inductive load < 1 H Capacitive load 100 nF Enclosure rating IP67: EN 60529 Temperature drift < 0.1 mm/K Lower signal level 3.8 mA ... 4 mA Upper signal level 20 mA ... 20.5 mA EMC EN 61326-2-3, 2014/30/EU - 1) All connections are polarity protected. All outputs are overload and short-circuit protected.
- MECHANICS
Wetted parts 1.4404, PTFE, FKM Process connection G ¾ A Housing material Plastic PBT Max. probe load ≤ 6 Nm
- AMBIENT DATA
Ambient operating temperature –20 °C ... +60 °C Ambient storage temperature –40 °C ... +80 °C
- CLASSIFICATIONS
ECl@ss 5.0 27371813 ECl@ss 5.1.4 27371813 ECl@ss 6.0 27371813 ECl@ss 6.2 27371813 ECl@ss 7.0 27371813 ECl@ss 8.0 27371813 ECl@ss 8.1 27371813 ECl@ss 9.0 27371813 ETIM 5.0 EC001447 ETIM 6.0 EC001447 UNSPSC 16.0901 41113710
