FEATURESSensor/ detection principlePhotoelectric proximity sensor, Background suppressionDimensions (W x H x D)10 mm x 28 mm x 18 mmHousing design (light emission)RectangularSensing range max.2 mm ... 100 mm 1)Type of lightVisible red lightLight sourceLED 2)Angle of dispersionApprox. 5°AdjustmentPotentiometer, 5 turns1) Object with 90 % reflectance (referred to standard white, DIN 5033).2) Average service life: 100,000 h at TU = +25 °C.MECHANICS/ELECTRONICSSupply voltage10 V DC ... 30 V DC 1)Ripple± 10 % 2)Power consumption20 mA 3)Switching outputPNPSwitching modeLight/dark switchingSwitching mode selectorSelectable via L/D control cableOutput current Imax.≤ 100 mAResponse time≤ 0.5 ms 4)Switching frequency1,000 Hz 5)Connection typeMale connector M8, 4-pinCircuit protection
A 6)
B 7)
C 8)
D 9)
Protection classIIWeight7 gHousing materialPlastic, ABSOptics materialPlastic, PCEnclosure ratingIP67Items suppliedBEF-W150-A mounting bracketAmbient operating temperature–25 °C ... +55 °CAmbient storage temperature–40 °C ... +75 °CUL File No.NRNT2.E128350 & NRNT8.E1283501) Limit values.2) May not exceed or fall below Uv tolerances.3) Without load.4) Signal transit time with resistive load.5) With light/dark ratio 1:1.6) A = VS connections reverse-polarity protected.7) B = inputs and output reverse-polarity protected.8) C = interference suppression.9) D = outputs overcurrent and short-circuit protected.CLASSIFICATIONSECl@ss 5.027270904ECl@ss 5.1.427270904ECl@ss 6.027270904ECl@ss 6.227270904ECl@ss 7.027270904ECl@ss 8.027270904ECl@ss 8.127270904ECl@ss 9.027270904ECl@ss 10.027270904ECl@ss 11.027270904ETIM 5.0EC002719ETIM 6.0EC002719ETIM 7.0EC002719UNSPSC 16.090139121528
