SKF LRM2 Series Lubrication Remote Monitor

Lubrication Remote Monitor

For monitoring lubrication systems in difficult-to-access locations

SKF’s LRM2 lubrication remote monitor is designed for use with lubrication systems that cannot be checked daily due to the nature or position of the specific application.

Compatible with oil or grease, the monitor can be used on single-line, dual-line and progressive lubrication systems. The LRM2 can communicate with a pump or group of pumps on the same type of lubrication system. LRM utilizes a SIM card to send and receive text messages via iOS or android mobile devices or via e-mail to a computer. The monitoring system can transmit alert messages to a random number of e-mail or mobile phone contacts. These contacts can be grouped based on the message type.

The LRM2 features two digital inputs and outputs and sends both low-level and fault messages. Also, the monitor can be used to start an additional lubrication cycle and can be reset by sending messages from the mobile device. In addition, you can access system information by using your web browser without having to install special software. The LRM is suitable for wind energy, railroad wayside, cable car and wastewater treatment applications, as well as other industries.

Features and benefits

• Two digital inputs and outputs
• Antenna is packed inside housing; optional external antenna can be ordered
• LRM2 module is available without housing for mounting in existing control box

applications

• Wind energy generators
• Cable cars
• Railroad (wayside lubrication)
• Wastewater treatment applications

Technical data

Function principle	lubrication remote monitor
Operating temperature	–30 to +70 °C	–22 to +158 °F
Storage temperature	–40 to +70 °C	–40 to +158 °F
Air humidity	0–95%
Protection class	IP 66
Screwed cable gland	M16
Clamping zone of cable strand	(ø) 4–10 mm	0,16–0,39 in
LRM2 clamping zone	0,25–2,5 mm	0.0098–0.098 in
Supply voltage	12–24 V DC (+/- 20%)
Power consumption	max. 3 W
Mounting position	any, but not rotating
Size	271×171×262 mm	10.67×6.73×10.31 in
Min. installation space	420×220×350 mm	16.53×8.66×13.78 in

Order information for use in North America

Part number	Description
236-13897-3	LRM2 only, with small antenna
237-11450-4	Enclosure only, without LRM2
236-11335-8	2G/3G Magnetic base antenna (3 m length)

Order information for use in Europe and Asia (no UL/CSA/FCC)

Part number	Description
LRM2-E-00-000	LRM2 for use in Europe and Asia for pump families P203, P603, P653 (without coupling relays), low-level and fault signal separately, without enclosure and antenna
LRM2-E-00-100	LRM2 for use in Europe and Asia for pump families P203, P603, P653 (without coupling relays), low-level and fault signal separately, with enclosure
LRM2-E-01-000	LRM2 for use in Europe and Asia for pump families P203, P603, P653 (without coupling relays), joint empty signal and fault signal, without enclosure and antenna
LRM2-E-01-100	LRM2 for use in Europe and Asia for pump families P203, P603, P653 (without coupling relays), joint empty signal and fault signal, with enclosure
LRM2-E-11-100	LRM2 for use in Europe and Asia for KFG series (with coupling relays and always in enclosure) (2 coupling relays), joint empty signal and fault signal, with enclosure and antenna
LRM2-E-20-000	LRM2 for use in Europe and Asia if 2 AC pumps are switched to one LRM (4 coupling relays), low-level and fault signal separately, without enclosure and antenna
LRM2-E-20-100	LRM2 for use in Europe and Asia if 2 AC pumps are switched to one LRM (4 coupling relays), low-level and fault signal separately, with enclosure
LRM2-E-21-000	LRM2 for use in Europe and Asia if 2 AC pumps are switched to one LRM (4 coupling relays), joint empty signal and fault signal, without enclosure and antenna
LRM2-E-21-100	LRM2 for use in Europe and Asia if 2 AC pumps are switched to one LRM (4 coupling relays), joint empty signal and fault signal, with enclosure
