Skf TMBS 150 E Puller Kit
Technical Datasheets / Product Documentations
| Brand |  |
| Category | Others |
| Product Name | Skf TMBS 150 E Puller Kit |
| Product Code | TMBS 150 E |
Contact with us! 24 business hours (excluding weekends and holidays) to confirm stock status and estimated delivery time.
Product Description
SKF products, including Skf TMBS 150 E Puller Kit, are sourced through parallel import channels and delivered to our customers worldwide with speed and reliability. As an authorized trading partner, Imtek Engineering offers genuine SKF parts at competitive prices. Even if Skf TMBS 150 E Puller Kit is not listed on our website, you are welcome to request a price quote — our team will respond promptly with a tailored offer.
TMBS 150E - Güçlü geri çektirmeler | SKF
Genel bakış Boyutlar Case dimensions (l x h x w)
580 x 410 x 70 mm
Total spindle length
505 mm (incl. 2 available extension pieces)
Özellikler Bağıl nem
max 75%
Dismounting force generation
Hydraulic spindle (TMHS 100)
Hydraulic spindle, piston stroke
80 mm
Kaplama
Black phosphated, Hydraulic spindle with trivalent chromium parts
Malzeme
Alloy engineering steels, hardened and tempered
Puller adaptor thread
UN 1.5 x 16 tpi
Pulling force (max)
100 kN
Reach, using separator (max)
816 mm (using all extension rods provided)
Renk
Black Silver
Separator height
34 mm
Shaft diameter range, using separator
35 to 150 mm
Spindle nose piece
yes, ⌀ 30mm
Suitable for bearing dismounting from a Sleeve (adapter or withdrawal sleeve)
Evet
Suitable for bearing dismounting from a Tapered seating (conical shaft)
Evet
Suitable for bearing type(s)
All
Suitable for workpiece dismounting from a Blind arrangement (housing with shaft)
Hayır
Suitable for workpiece dismounting from a Cylindrical seating (straight shaft)
Evet
Suitable for workpiece dismounting from a Housing
Hayır
Workpiece outer diameter range, using separator
44 to 215 mm
Önerilen depolama sıcaklığı
5 – 40 °C
Önerilen uygulamalar
For dismounting of bearings, gears, pulleys and other industrial ring shaped components from shafts in
industrial, construction and agricultural applications, where there is limited space behind the component
and traditional jaw pullers won't fit.
Özel özellikler
Provide the possibility to engage the inner ring of the bearing, thus making sure that no withdrawal force
is transmitted through the rolling elements Comes with various extension rods to allow useage on longer shafts
Hydraulic spindle with integrated safety valve for safer use
İçerik
1 x separator set 1 x beam 2 x main rods 4 x extension rods, 285 mm 2 x extension rods, 125 mm
1 x hydraulic spindle TMHS 100 (with handle bar) 2 x extension pieces for hydraulic spindle
50, 100 mm 1 x nosepiece with centre point for hydraulic spindle
IFU QR Code card Case
Lojistik Ürün net ağırlığı
17.6 kg
eClass kodu
23-05-19-01
UNSPSC kodu
27111712
Uyumlu ürünler Accessory Puller protection blanket
TMMX 350
Spare part Spare main rods set with washers and nuts for Strong back pullers or Hydraulic puller kit
TMBS 100E-2
Spare extension rods set, short, for Strong back pullers or Hydraulic puller kit
TMBS 100E-3
