Effortless bearing dismounting up to 100 Kn
The SKF TMHP 10E jaw puller kit is equipped with a hydraulic spindle, which facilitates effortless bearing dismounting up to 100 kN (11.2 ton US). The versatile puller kit includes three different arm sizes and can be assembled as a two-arm puller or a three-arm puller depending on the space and demand of the application.
Technical data
Designation
TMHP 10E
Description
Advanced hydraulic jaw puller kit
Contents
1 x arm-assembly stand
3 x arms, 115 mm (4.5 in.)
3 x arms, 160 mm (6.3 in.)
3 x arms, 200 mm (7.8 in.)
1 x hydraulic spindle TMHS 100
3 x extension pieces for hydraulic spindle; 50, 100, 150 mm (2, 4, 6 in.)
1 x nosepiece with centre point for hydraulic spindle
Maximum stroke
80 mm (3.1 in.)
Weight complete kit
14,5 kg (32 lb)
Cycle life hydraulic cylinder
Minimum 5000 cycles up to 100 kN (11.2 US ton force)
Threading hydraulic cylinder
UN 1½'' x 16 tpi
Safety valve setting hydraulic cylinder
105 kN (11.8 US ton force)
Carrying case dimensions
578 x 410 x 70 mm (23 x 16 x 2.8 in.)
Nominal working force
100 kN (11.2 US ton force)
Arm set 1 (3 x TMHP 10E-10)
Effective arms length
115 mm (4.5 in.)
Width of grip
75-170 mm (3.0-6.7 in.)
Claw height
8 mm (0.3 in.)
Arm set 2 (3 x TMHP 10E-11)
Effective arms length
160 mm (6.3 in.)
Width of grip
80-250 mm (3.1-9.8 in.)
Claw height
8 mm (0.3 in.)
Arm set 3 (3 x TMHP 10E-12)
Effective arms length
200 mm (7.9 in.)
Width of grip
110-280 mm (4.3-11 in.)
Claw height
8 mm (0.3 in.)
Spare parts
Designation
Description
TMHS 100
Advanced hydraulic spindle, 100 kN
TMHS 100-1
Advanced hydraulic spindle, 100 kN, spindle only
TMHS 8T
Set of extension pieces and nose piece for TMHS 100 and 8E
TMHP 10E-5
Four arm stand with bolts and nuts for TMHP 10E and TMHC 110E
TMHP 10E-10
Arm for TMHP 10E and TMHC 110E, 190 mm long
TMHP 10E-11
Arm for TMHP 10E, 240 mm long
TMHP 10E-12
Arm for TMHP 10E, 285 mm long
