SKF W 60/1.5 R Deep Groove Ball Bearing

SKF

Product Code: W 60/1.5 R
Brand: SKF



GET OFFER: info@imtek.com.tr

Description for SKF W 60/1.5 R Deep Groove Ball Bearing

Technical specification MetricImperial DIMENSIONS d 1.5 mmD 6 mmB 2.5 mmd1? 3 mmD1? 4.8 mmD3 7.5 mmC 0.6 mmr1,2min. 0.15 mm ABUTMENT DIMENSIONS damin. 2.3 mmramax. 0.15 mm CALCULATION DATA Basic dynamic load ratingC 0.19 kNBasic static load ratingC0 0.051 kNFatigue load limitPu 0.002 kNReference speed 180000 r/minLimiting speed 110000 r/minCalculation factorkr 0.03Calculation factorf0 6 MASS Mass bearing 0.001 kg
