Sumitomo IB Series P2 Type Motion Control

Sumitomo

Product Code: IB Series P2 Type
Brand: Sumitomo



GET OFFER: info@imtek.com.tr

Description for Sumitomo IB Series P2 Type Motion Control

OverviewPrecision planetary line for miscellaneous automation applications in the upper torque range. High torque density unit with angular ball bearings for high load capacity Adaptable servo motor connection Simple motor assembly with clamp ring connection Maintenance free for life Helical gears for lowest vibration and noise Output Shaft Variants: Flange Solid Shaft KeywayTechnical InfoMechanical Backlash <3 arcmin Number of Sizes 2 Reduction Ratios 4 / 5 / 7 /10 / 16 / 20 / 25 / 28 / 35 / 40 / 50 / 70 / 100 Nominal Output Torque 500 Nm up to 1500 nm Acceleration Torque 650 Nm up to 3000 Nm Max. Momentary Peak Torque 1500 Nm up to 5250 Nm Input speed up to 6000 rpm Max. Bending Moment 1177 Nm up to 2000 Nm Max. Radial load 10245 N up to 18385 N Max. Axial Load 5200 N up to 8100 N
