Turbo TF045(N-V-T)P Pulse Valves with Threaded Connections

Turbo

Product Code: TF045(N-V-T)P
Brand: Turbo

GET OFFER: info@imtek.com.tr

Description for Turbo TF045(N-V-T)P Pulse Valves with Threaded Connections

Fluids: Non-lubricated filtered air Operating temperature Neoprene diaphragm:From -20°C to +80°C Operating temperature Viton diaphragm:From -20°C to +200°C Operating temperature Low Temperature diaphragm:From -40°C to +80°C Operating pressure: From 0,5 Bar to 7,5 Bar Body and Cover: Die-cast aluminium Pilot unit: Stainless steel Screws and bolts: Stainless steel Coil Insulation: Class H Connector: PG 9 EN175301-803 Connector + coil protection: IP65 EN60529 Standard voltage: 24 V/50-60Hz (±10%) 19VA 115 V/50-60Hz (±10%) 19VA 230 V/50-60Hz (±10%) 19VA 24 VDC (±10%) 18Watt
