Turbo TS035(N-V-T)MWE Pulse Valve for Flat Surfaces

Turbo

Product Code: TS035(N-V-T)MWE
Brand: Turbo



GET OFFER: info@imtek.com.tr

Description for Turbo TS035(N-V-T)MWE Pulse Valve for Flat Surfaces

Fluids:                                      Non-lubricated filtered air Operating temperature Neoprene diaphragm:From -20°C to +80°C Operating temperature Viton diaphragm:From -20°C to +200°C Operating temperature Low Temperature diaphragm:From -40°C to +80°C Operating pressure:                From 0,5 Bar to 7,5 Bar Body and Cover:                     Die-cast aluminium Pilot unit:                                 Stainless steel Screws and bolts:                   Stainless steel Coil Insulation:                        Class H Connector:                              PG 9 EN175301-803 Connector + coil protection:    IP65 EN60529 Standard voltage:                   24 V/50-60Hz (±10%) 19VA                                                115 V/50-60Hz (±10%) 19VA                                                230 V/50-60Hz (±10%) 19VA                                                24 VDC (±10%) 18Watt
