Unimec RZ86-S8-R-1-1-2-14B  Reducer Image

Unimec RZ86-S8-R-1-1-2-14B Reducer

Unimec

Product Code: RZ86-S8-R-1-1-2-14B
Brand: Unimec



GET OFFER: info@imtek.com.tr

Description for Unimec RZ86-S8-R-1-1-2-14B Reducer

MaterialsMaterialNormativeSpecificationIndicationsHub shaftC45EN 10083-2:2006Carbon steelCarterGJL 250EN 1561:2011Grey cast ironCompletely machined on 6 facesBevel gears17NiCrMo 6-4EN 10084:2008Casehardening alloy steelGround bores and planes. Gleason gears run by pair.LubricantUnimec Atir SH150Synthetic oil0,1 ltGeneral featuresGear backlash15' - 20'Forced lubrication speed3000 rpmGrease lubrication speed100 rpmOperating temperature [°C]-10 °C / 80 °CMaximum input speed4500 rpmMain gearbox weight6,5 kgSpecific featuresNominal ratios1/11/1,51/21/31/4Phase between keys+/- 6,5°+/- 6°+/- 6°+/- 6°+/- 4,5°Inertia moment366 kg-mm2136 kg-mm274 kg-mm237 kg-mm226 kg-mm2Power curvesThe magenta zone indicates a potential heating risk. Working cycles must be carefully analized.S = Rotational speed of the fast/slow shaft [rpm]CL = Slow shaft torque [Nm]P = requested input power [kW]Max admissible loadsAdmissible loadsS = Fast shaft rotational speed [rpm]RL = Admissible radial load [kN]AL = Admissible axial load [kN]HS = Hub shaftRHS = reinforced hub shaftPS = Solid protruding shaft  Specific accessoriesThe accessories avaiable for this product are reported below
