Wilkerson F18-02-SGVO Particulate Filter

Wilkerson

Product Code: F18-02-SGVO - FILTER, PARTICULATE
Brand: Wilkerson



GET OFFER: info@imtek.com.tr

Description for Wilkerson F18-02-SGVO Particulate Filter

FeaturesThis modular particulate filter includes:Standard 5 Micron FiltrationHigh Flow Capacities1/2" NPT / BSPP-G Over-portQuick-disconnect BowlBowl GuardLight WeightBarbed Manual Drain Connection with Pipe-awaySpecificationsFlow Capacity*1/4"50 SCFM (24 dm3/s, ANR)3/8"78 SCFM (37 dm3/s, ANR)1/2"82 SCFM (39 dm3/s, ANR)Maximum Supply PressurePlastic Bowl150 PSIG (10.3 bar)Metal Bowl250 PSIG (17.2 bar)Operating TemperaturePlastic Bowl-13° to 125°F (-25° to 52°C)Metal Bowl-13° to 150°F (-25° to 65.5°C)Port SizeNPT / BSPP-G1/4, 3/8, 1/2Standard Filtration5 MicronWeight0.62 lb. (0.28 kg)* Inlet pressure 91.3 psig (6.3 bar). Pressure drop 4.9 psig (0.34 bar)."F" Series Filters, Type "A" 5 micron elements: All Wilkerson Type "A"5 micron elements meet or exceed ISO Class 3 for maximum particle size and concentration of solid contaminants.Air Quality: Within ISO 8573-1: 1991 Class 3 (Particulates); Within ISO 8573-1: 2001 Class 6 (Particulates)
