Zander Aachen ZCode-LR 941149 Actuator

Zander Aachen

Product Code: ZCode-LR 941149
Brand: Zander Aachen

GET OFFER: info@imtek.com.tr

Description for Zander Aachen ZCode-LR 941149 Actuator

ZCode-LR RFIDApplicationsHigh requirements on manipulation (high anti-tamper level), suitable for small and poorly aligned guard doors, sliding guards or protective coversCertified according toISO 13849-1; EN 62061, EN ISO 14119; EN 60204-1; EN 60947-5-3; EN 1088; UL508ApprovalsCE, TUV, ULSemiconductor outputs2 contactless safety outputs, 1 auxiliary outputsAuxiliary contacts1Contact rating (safe- & auxiliary outputs)DC 24 V, max. 200 mA, short circuit proofSupply VoltageDC 24 V; +/- 15 %, max. 50 mASwitching distance5 mm, 10 mm close / 20 mm openBase materialRed PES (Polyester)ProtectionIP67, IP69K (only Stainless Steel)Ambient temperature-25 °C to +80 °CPL; Cat.; (EN ISO 13849-1; EN 62061)PL e; Cat.4Vibration- , shock resistance10-55 Hz / 1 mm, 1 ms / 30 gWeight, dimensions200 g, 88 x 25 x 13 mmOrder No. with 5 m cable, mastercode, incl. actuator941144Order No. with M12 connector, mastercode, incl. actuator941145Order No. with 5 m cable, unicode, incl. actuator941154Order No. with M12 connector, unicode, incl. actuator941155AccessoriesOrder No. spare actuator941149 (Mastercode)Order No. M12 extension cable, 10 m lengths, female, 8-wire, open end cable941200
