BECKHOFF EL6652 EtherNet/IP master terminal

EL6652 | EtherNet/IP master terminal The EL6652 EtherNet/IP-Master Terminal has a switched 2-port Ethernet connection and can thus be operated in a line with further Ethernet/IP nodes. The process data are configured by an EtherCAT master, allowing different process data and different sizes. The EL6652 supports both multicast and unicast connections. Up to 16 simple EtherNet/IP-Slave devices can be connected via one generic node. The EL6652 is optionally also available as a slave version. Technical data EL6652 EL6652-0010 Technology EtherNet/IP master terminal EtherNet/IP slave terminal Number of ports/channels 2 (switched) Ethernet interface 100BASE-TX Ethernet with 2 x RJ45 Data length max. 1 kByte input and output data – Cable length up to 100 m twisted pair Hardware diagnosis status LEDs Power supply via the E-bus Electrical isolation 500 V (E-bus/Ethernet) Protocol EtherNet/IP EtherNet/IP slave Configuration via EtherCAT master Current consumption E-bus typ. 400 mA Special features multicast/unicast connection Weight approx. 75 g Operating/storage temperature 0…+55 °C/-25…+85 °C Relative humidity 95 %, no condensation Vibration/shock resistance conforms to EN 60068-2-6/EN 60068-2-27 EMC immunity/emission conforms to EN 61000-6-2/EN 61000-6-4 Protect. class/installation pos. IP 20/see documentation Approvals/markings CE, UL Ordering information EL6652 EtherNet/IP master terminal, 2 x RJ45 switch EL6652-0010 EtherNet/IP slave terminal System EtherNet/IP For further EtherNet/IP products please see the system overview.
