BECKHOFF KL2424 4-channel digital output terminal
技术数据表 / 产品文档
- 目前暂无此产品的技术文档。如需更多信息，请与我们联系。
| 品牌 |  |
| 类别 | 端子 |
| 产品名称 | BECKHOFF KL2424 4-channel digital output terminal |
| 产品编号 | KL2424 |
欢迎联系我们！我们会在 24 个工作小时内（不含周末及节假日）确认库存状态和预计交期。
产品描述
BECKHOFF的产品（包括BECKHOFF KL2424 4-channel digital output terminal）通过平行进口渠道采购，并快速可靠地交付给United States的客户。Imtek Engineering以具有竞争力的价格提供正品BECKHOFF零部件。即使BECKHOFF KL2424 4-channel digital output terminal未在我们的网站上列出，您也可以随时申请报价——我们的团队将迅速响应并为您提供专属报价。
United StatesThe KL2404 and KL2424 digital output terminals connect the binary 24 V control signals electrically isolated with the actuators. The Bus Terminals contain four channels that indicate their signal state by means of LEDs. The variants KL2404 and KL2424 have different maximum output currents. The 4-channel Bus Terminals enable the direct connection of four 2-wire sensors. Four ground connection points are provided.
| Technical data | KL2404 | KS2404 | KL2424 | KS2424 |
|---|---|---|
| Connection technology | 2-wire | |
| Number of outputs | 4 | |
| Rated load voltage | 24 V DC (-15 %/+20 %) | |
| Load type | ohmic, inductive, lamp load | |
| Max. output current | 0.5 A (short-circuit-proof) per channel | 2.0 A (short-circuit-proof) per channel |
| Short circuit current | < 2 A | < 70 A |
| Breaking energy | < 150 mJ/channel | < 1.7 J/channel |
| Reverse voltage protection | yes | |
| Electrical isolation | 500 V (K-bus/field potential) | |
| Current consumption power contacts | typ. 30 mA + load | |
| Current consumpt. K-bus | typ. 9 mA | |
| Bit width in the process image | 4 outputs | |
| Configuration | no address or configuration setting | |
| Weight | approx. 70 g | |
| Operating/storage temperature | -25…+60 °C/-40…+85 °C | |
| Relative humidity | 95 %, no condensation | |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 | |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 | |
| Protect. class/installation pos. | IP 20/variable | |
| Pluggable wiring | for all KSxxxx Bus Terminals | |
| Approvals | CE, UL, Ex | CE, UL, Ex, GL |
