BECKHOFF KS1434 4-channel digital input terminal 24 VDC
技术数据表 / 产品文档
- 目前暂无此产品的技术文档。如需更多信息，请与我们联系。
| 品牌 |  |
| 类别 | 端子 |
| 产品名称 | BECKHOFF KS1434 4-channel digital input terminal 24 VDC |
| 产品编号 | KS1434 |
欢迎联系我们！我们会在 24 个工作小时内（不含周末及节假日）确认库存状态和预计交期。
产品描述
BECKHOFF的产品（包括BECKHOFF KS1434 4-channel digital input terminal 24 VDC）通过平行进口渠道采购，并快速可靠地交付给United States的客户。Imtek Engineering以具有竞争力的价格提供正品BECKHOFF零部件。即使BECKHOFF KS1434 4-channel digital input terminal 24 VDC未在我们的网站上列出，您也可以随时申请报价——我们的团队将迅速响应并为您提供专属报价。
United StatesKL1434 | 4-channel digital input terminal 24 V DC
The KL1434 digital input terminal acquires the binary 24 V control signals and transmits them, in an electrically isolated form, to the higher-level automation unit. The Bus Terminal contains four channels that indicate their signal state by means of LEDs. The input signal of the KL1434 corresponds to corresponds to EN 61131-2 type 2. The 4-channel Bus Terminals enable the direct connection of four 2-wire sensors. Four +24 V connection points are provided.
| Technical data | KL1434 | KS1434 |
|---|---|
| Connection technology | 2-wire |
| Specification | EN 61131-2, type 2 |
| Number of inputs | 4 |
| Nominal voltage | 24 V DC (-15 %/+20 %) |
| “0“ signal voltage | -3…+5 V (EN 61131-2, type 2) |
| “1“ signal voltage | 11…30 V (EN 61131-2, type 2) |
| “0“ signal current | – |
| “1“ signal current | typ. 6 mA (EN 61131-2, type 2) |
| Input filter | typ. 0.2 ms |
| Current consumpt. K-bus | typ. 3 mA |
| Electrical isolation | 500 V (K-bus/field potential) |
| Bit width in the process image | 4 inputs |
| Configuration | no address or configuration setting |
| Weight | approx. 50 g |
| Operating/storage temperature | 0…+55 °C/-25…+85 °C |
| Relative humidity | 95 %, no condensation |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Protect. class/installation pos. | IP 20/variable |
| Pluggable wiring | for all KSxxxx Bus Terminals |
| Approvals | CE, UL, Ex |
| Product announcement | KL1434: available KS1434: estimated market release on request |
