BECKHOFF KS1501 Up/down counter 24 V DC, 100 kHz
技术数据表 / 产品文档
- 目前暂无此产品的技术文档。如需更多信息，请与我们联系。
| 品牌 |  |
| 类别 | 其他 |
| 产品名称 | BECKHOFF KS1501 Up/down counter 24 V DC, 100 kHz |
| 产品编号 | KS1501 |
欢迎联系我们！我们会在 24 个工作小时内（不含周末及节假日）确认库存状态和预计交期。
产品描述
BECKHOFF的产品（包括BECKHOFF KS1501 Up/down counter 24 V DC, 100 kHz）通过平行进口渠道采购，并快速可靠地交付给United States的客户。Imtek Engineering以具有竞争力的价格提供正品BECKHOFF零部件。即使BECKHOFF KS1501 Up/down counter 24 V DC, 100 kHz未在我们的网站上列出，您也可以随时申请报价——我们的团队将迅速响应并为您提供专属报价。
United StatesKL1501 | Up/down counter 24 V DC, 100 kHz
The KL1501 Bus Terminal is an up/down counter. It transmits the counter state to the higher-level automation device in an electrically isolated manner. When it is used as a single-channel up/down counter (32 bit), the pulse is set via the clock input, while the count direction is set via the up/down input. The input can also be used as a gate input for triggering the counter. In two-counter mode, two separate counters (Clock and Clock1 inputs) with each 16 bit are available, which can be parameterised as up or down counters. The signal state of the inputs and outputs is indicated by light emitting diodes. Both outputs are switched according to the counter state, so that they can be used as fast control signals for field devices.
| Technical data | KL1501 | KS1501 |
|---|---|
| Connection technology | 1 x up/down counter, 2 x up or down counter |
| Specification | EN 61131-2, type 1, “0”: < 5 V DC, “1”: > 15 V DC, typ. 5 mA |
| Number of counters | 1 or 2 |
| Nominal voltage | 24 V DC (-15 %/+20 %) |
| “0” signal voltage | -3…+5 V (EN 61131-2, type 1) |
| “1” signal voltage | 15…30 V (EN 61131-2, type 1) |
| Counting frequency | max. 100 kHz (2 kHz for switching between up and down) |
| Counter depth | 32 bit |
| Input current | typ. 5 mA (EN 61131-2, type 1) |
| Max. output current | 24 V/0.5 A (short-circuit proof) per channel |
| Current consumption K-bus | typ. 50 mA |
| Current consumption power contacts | load only |
| Electrical isolation | 500 V (K-bus/field potential) |
| Bit width in the process image | 40 inputs/outputs: 32 bit data, 8 bit control/status |
| Configuration | no address setting, configuration via Bus Coupler or controller |
| Special features | set counters, switch outputs |
| Weight | approx. 50 g |
| Operating/storage temperature | -25…+60 °C/-40…+85 °C |
| Relative humidity | 95 %, no condensation |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Protect. class/installation pos. | IP 20/variable |
| Pluggable wiring | for all KSxxxx Bus Terminals |
| Approvals | CE, UL, Ex, IECEx |
| Special terminals | |
|---|---|
| KL1501-0010 | gate-counter with auto-reset and setting A0 |
| KL1501-0011 | up/down counter with 5 V inputs, 24 V DC outputs |
