  4. SICK 1038824 Type:A3M60B-S4PB013x13 Absolute Encoder

SICK 1038824 Type:A3M60B-S4PB013x13 Absolute Encoder

Technical Documentation

技术数据表 / 产品文档

  • 目前暂无此产品的技术文档。如需更多信息，请与我们联系。
WhatsApp
品牌
SICK logo - Official brand
类别編碼器
产品名称SICK 1038824 Type:A3M60B-S4PB013x13 Absolute Encoder
产品编号1038824
Visa – Secure credit card payment acceptedMastercard – Secure credit card payment acceptedAmerican Express – Secure credit card payment acceptedDiners Club – Secure credit card payment acceptedDiscover – Secure credit card payment accepted

欢迎联系我们！我们会在 24 个工作小时内（不含周末及节假日）确认库存状态和预计交期。

产品描述

SICK的产品（包括SICK 1038824 Type:A3M60B-S4PB013x13 Absolute Encoder）通过平行进口渠道采购，并快速可靠地交付给United States的客户。Imtek Engineering以具有竞争力的价格提供正品SICK零部件。即使SICK 1038824 Type:A3M60B-S4PB013x13 Absolute Encoder未在我们的网站上列出，您也可以随时申请报价——我们的团队将迅速响应并为您提供专属报价。

  • PERFORMANCE
    Max. resolution (number of steps per revolution x number of revolutions)13 bit x 13 bit (8,192 x 8,192)
    Error limits G0.5° (at room temperature) 1)
    Repeatability standard deviation σr0.25° (at room temperature) 2)
    • 1) In accordance with DIN ISO 1319-1, position of the upper and lower error limit depends on the installation situation, specified value refers to a symmetrical position, i.e. deviation in upper and lower direction is the same.
    • 2) In accordance with DIN ISO 55350-13; 68.3% of the measured values are inside the specified area.
  • INTERFACES
    Communication interfacePROFIBUS DP
    Communication Interface detailDPV0
    Data transmission rate (baud rate)≤ 12 MBaud
    Parameterising dataNumber of steps per revolution, number ofrevolutions, PRESET, counting direction
    Bus terminationDIP switch
    Initialization timeApprox. 1 s
  • ELECTRICAL DATA
    Connection type

    Male connector, 2 x M12, 5-pin, axial

    Female connector, 1 x M12, 5-pin, axial

    Supply voltage10 ... 32 V
    Reverse polarity protection✔
    MTTFd: mean time to dangerous failure60 years (EN ISO 13849-1) 1)
    • 1) This product is a standard product and does not constitute a safety component as defined in the Machinery Directive. Calculation based on nominal load of components, average ambient temperature 40°C, frequency of use 8760 h/a. All electronic failures are considered hazardous. For more information, see document no. 8015532.
  • MECHANICAL DATA
    Mechanical designSolid shaft, face mount flange
    Shaft length19 mm
    Shaft diameter10 mm
    Weight0.28 kg
    Shaft materialStainless steel
    Flange materialAluminum
    Housing materialAluminum
    Start up torque1 Ncm
    Operating torque0.8 Ncm
    Permissible Load capacity of shaft

    80 N / radial

    40 N / axial

    Bearing lifetime3.0 x 10^9 revolutions
    Angular acceleration≤ 500,000 rad/s²
    Operating speed≤ 6,000 min⁻¹ self warming 30 K at maximum operating speed
  • AMBIENT DATA
    EMCAccording to EN 61000-6-2 and EN 61000-6-3
    Enclosure rating

    IP67, housing (according to IEC 60529) 1)

    IP65, Shaft (according to IEC 60529)

    Permissible relative humidity95 % (Condensation not permitted)
    Operating temperature range–10 °C ... +70 °C
    Storage temperature range–40 °C ... +100 °C
    Resistance to shocks100 g, 6 ms (according to EN 60068-2-27)
    Resistance to vibration30 g, 10 Hz ... 2,000 Hz (according to EN 60068-2-6)
    • 1) With mating connector fitted.
  • CLASSIFICATIONS
    ECl@ss 5.027270502
    ECl@ss 5.1.427270502
    ECl@ss 6.027270590
    ECl@ss 6.227270590
    ECl@ss 7.027270502
    ECl@ss 8.027270502
    ECl@ss 8.127270502
    ECl@ss 9.027270502
    ETIM 5.0EC001486
    ETIM 6.0EC001486
    UNSPSC 16.090141112113
