SICK 6052386 Type: WL100-2P4429 Photoelectric sensor
技术数据表 / 产品文档
- 目前暂无此产品的技术文档。如需更多信息，请与我们联系。
| 品牌 |  |
| 类别 | 傳感器 |
| 产品名称 | SICK 6052386 Type: WL100-2P4429 Photoelectric sensor |
| 产品编号 | 6052386 |
欢迎联系我们！我们会在 24 个工作小时内（不含周末及节假日）确认库存状态和预计交期。
产品描述
SICK的产品（包括SICK 6052386 Type: WL100-2P4429 Photoelectric sensor）通过平行进口渠道采购，并快速可靠地交付给United States的客户。Imtek Engineering以具有竞争力的价格提供正品SICK零部件。即使SICK 6052386 Type: WL100-2P4429 Photoelectric sensor未在我们的网站上列出，您也可以随时申请报价——我们的团队将迅速响应并为您提供专属报价。
United States- FEATURES
Sensor/ detection principle Photoelectric retro-reflective sensor, Dual lens Dimensions (W x H x D) 11 mm x 31 mm x 20 mm Housing design (light emission) Rectangular Sensing range max. 0.01 m ... 3 m 1) Sensing range 0.01 m ... 2.5 m 1) Type of light Visible red light Light source LED 2) Light spot size (distance) Ø 140 mm (2 m) Wave length 632 nm Adjustment Potentiometer (Sensitivity) Special applications Detecting transparent objects Special features Detecting transparent objects - 1) Reflector PL80A.
- 2) Average service life: 100,000 h at TU = +25 °C.
- MECHANICS/ELECTRONICS
Supply voltage 10 V DC ... 30 V DC 1) Ripple ± 10 % 2) Power consumption 30 mA 3) Switching output PNP Switching mode Light/dark switching Switching mode selector Selectable via light/dark rotary switch Signal voltage PNP HIGH/LOW UV - 1,8 V / ca. 0 V Output current Imax. 100 mA Response time ≤ 0.5 ms 4) Switching frequency 1,000 Hz 5) Attenuation along light beam ≥ 20 % Connection type Male connector M8, 4-pin Circuit protection A 6)
B 7)
D 8)
Protection class III Housing material Plastic, ABS/PC/POM Optics material Plastic, PMMA Enclosure rating IP67 Items supplied Mounting bracket BEF-W100-A, Reflector P250 Special feature Detecting transparent objects Ambient operating temperature –25 °C ... +55 °C Ambient storage temperature –40 °C ... +70 °C - 1) Limit values.
- 2) May not exceed or fall below Uv tolerances.
- 3) Without load.
- 4) Signal transit time with resistive load.
- 5) With light/dark ratio 1:1.
- 6) A = VS connections reverse-polarity protected.
- 7) B = output reverse-polarity protected.
- 8) D = outputs overcurrent and short-circuit protected.
- SAFETY-RELATED PARAMETERS
MTTFD 954 years DCavg 0%
- CLASSIFICATIONS
ECl@ss 5.0 27270902 ECl@ss 5.1.4 27270902 ECl@ss 6.0 27270902 ECl@ss 6.2 27270902 ECl@ss 7.0 27270902 ECl@ss 8.0 27270902 ECl@ss 8.1 27270902 ECl@ss 9.0 27270902 ECl@ss 10.0 27270902 ECl@ss 11.0 27270902 ETIM 5.0 EC002717 ETIM 6.0 EC002717 ETIM 7.0 EC002717 UNSPSC 16.0901 39121528
