SICK 1037450 type: DFS60E-BECK01000 Incremental encoder
技术数据表 / 产品文档
- 目前暂无此产品的技术文档。如需更多信息，请与我们联系。
| 品牌 |  |
| 类别 | 編碼器 |
| 产品名称 | SICK 1037450 type: DFS60E-BECK01000 Incremental encoder |
| 产品编号 | DFS60E-BECK01000 |
欢迎联系我们！我们会在 24 个工作小时内（不含周末及节假日）确认库存状态和预计交期。
产品描述
SICK的产品（包括SICK 1037450 type: DFS60E-BECK01000 Incremental encoder）通过平行进口渠道采购，并快速可靠地交付给United States的客户。Imtek Engineering以具有竞争力的价格提供正品SICK零部件。即使SICK 1037450 type: DFS60E-BECK01000 Incremental encoder未在我们的网站上列出，您也可以随时申请报价——我们的团队将迅速响应并为您提供专属报价。
United States- PERFORMANCE
Pulses per revolution 1,000 Measuring step 90° electronically/ppr Measuring step deviation at non binary number of lines ± 0.2° Error limits ± 0.3° Initialization time 40 ms
- INTERFACES
Communication interface Incremental Communication Interface detail TTL / RS-422 Number of signal channels 6-channel
- ELECTRICAL DATA
Connection type Cable, 8-wire, universal, 1.5 m Operating current 40 mA Power consumption ≤ 0.5 W (without load) Supply voltage 10 ... 32 V Load current ≤ 30 mA Output frequency ≤ 300 kHz Reference signal, number 1 Reference signal, position 90°, electric, logically gated with A and B Reverse polarity protection ✔ Short-circuit protection of the outputs ✔ 1) MTTFd: mean time to dangerous failure 300 years (EN ISO 13849-1) 2) - 1) Short-circuit opposite to another channel or GND permissable for maximum 30 s.
- 2) This product is a standard product and does not constitute a safety component as defined in the Machinery Directive. Calculation based on nominal load of components, average ambient temperature 40°C, frequency of use 8760 h/a. All electronic failures are considered hazardous. For more information, see document no. 8015532.
- MECHANICAL DATA
Mechanical design Blind hollow shaft Shaft diameter 12 mm Weight 0.2 kg Shaft material Metal Flange material Aluminum Housing material Aluminum die cast Start up torque 0.8 Ncm (+20 °C) Operating torque 0.6 Ncm (+20 °C) Permissible shaft movement, axial static/dynamic ± 0.5 mm / ± 0.2 mm Permissible shaft movement, radial static/dynamic ± 0.3 mm / ± 0.1 mm Operating speed ≤ 6,000 min⁻¹ 1) Moment of inertia of the rotor 40 gcm² Bearing lifetime 3.6 x 10^10 revolutions Angular acceleration ≤ 500,000 rad/s² - 1) Allow for self-heating of 3.3 K per 1,000 rpm when designing the operating temperature range.
- AMBIENT DATA
EMC According to EN 61000-6-2 and EN 61000-6-3 Enclosure rating IP67, housing side, cable connection (according to IEC 60529)
IP65, shaft side (according to IEC 60529)
Permissible relative humidity 90 % (condensation of the optical scanning not permitted) Operating temperature range 0 °C ... +85 °C Storage temperature range –40 °C ... +100 °C, without package Resistance to shocks 50 g, 6 ms (according to EN 60068-2-27) Resistance to vibration 20 g, 10 Hz ... 2,000 Hz (according to EN 60068-2-6)
- CLASSIFICATIONS
ECl@ss 5.0 27270501 ECl@ss 5.1.4 27270501 ECl@ss 6.0 27270590 ECl@ss 6.2 27270590 ECl@ss 7.0 27270501 ECl@ss 8.0 27270501 ECl@ss 8.1 27270501 ECl@ss 9.0 27270501 ECl@ss 10.0 27270501 ECl@ss 11.0 27270501 ETIM 5.0 EC001486 ETIM 6.0 EC001486 UNSPSC 16.0901 41112113
