SICK 1026287 type: UE403-A0930 Safety relay

SAFETY-RELATED PARAMETERSSafety integrity level

SIL3 (IEC 61508)

SILCL3 (EN 62061)

CategoryCategory 4 (EN ISO 13849)Performance levelPL e (EN ISO 13849)PFHD (mean probability of a dangerous failure per hour)1.0 x 10-8 (EN ISO 13849) 1)TM (mission time)20 years (EN ISO 13849) 1)1) Only in conjunction with M4000 Advanced, M4000 Advanced A/P and M4000 Advanced Curtain.FUNCTIONSConcurrence monitoring✔Monitoring of total muting time✔Sensor gap monitoring✔Belt stop✔Muting with override✔Exit monitoring✔End of muting by ESPE✔INTERFACESConnection typeFemale connector M12, 5-pinELECTRICAL DATAProtection classIII (IEC 61140)Supply voltage VS24 V DC (19.2 V DC ... 28.8 V DC) 1)Power consumption≤ 2 AInputs: override, reset, C1, belt stop, muting sensorsON state, switching voltage HIGH24 V DC (11 V DC ... 30 V DC)OFF state, switching voltage LOW0 V DC (–30 V DC ... 5 V DC)Input current HIGH6 mA ... 15 mAInput current LOW–0.5 mA ... 1.5 mAOutputs: voltage supply for reset, override, C1Supply voltage24 V DC (15 V DC ... 28.8 V DC)Output current≤ 400 mA 2)Outputs: muting sensorsSupply voltage24 V DC (15 V DC ... 28.8 V DC)Output current≤ 500 mA 2)Muting lampOutput current HIGH (monitored)20 mA ... 400 mA 3)Output current HIGH (not monitored)0 mA ... 400 mA 3)1) Via connected ESPE.2) Total of all supply currents from the connections RES/OVR, A1, A2, B1 and B2 (pin 1 in each case): max. 1000 mA.3) At max. 5 W power consumption.MECHANICAL DATADimensions (W x H x D)76.5 mm x 225.2 mm x 40 mmWeight+ 600 gMountingFlexible mounting on the M4000 Advanced or directly in the systemAMBIENT DATAEnclosure ratingIP65 (IEC 60529)Ambient operating temperature–30 °C ... +55 °CStorage temperature–30 °C ... +70 °CCLASSIFICATIONSECl@ss 5.027371990ECl@ss 5.1.427371990ECl@ss 6.027371819ECl@ss 6.227371819ECl@ss 7.027371819ECl@ss 8.027371819ECl@ss 8.127371819ECl@ss 9.027371819ECl@ss 10.027371819ECl@ss 11.027371819ETIM 5.0EC001449ETIM 6.0EC001449ETIM 7.0EC001449UNSPSC 16.090141113704
